Black & Decker FSM1630 [4/12] Assembly

ENGLISH

(Original instructions)

Intended use

Your Black & Decker steam mop has been designed for

sanitising and cleaning sealed hardwood, sealed laminate,

linoleum, vinyl, ceramic tile, stone and marble oors and for

refreshing carpets. This appliance is intended for indoor

household use only.

Warning! Read all of the 'Safety, Maintenance,

Service' manual carefully before operating

this appliance.

Read all of this manual carefully before operating

the appliance.

Features

This appliance includes some or all of the following features.

1. ON/Off switch

2. Autoselect

button

3. Removable water tank

4. Handle

5. Steam head

6. Steam head cleaning pad

7. Delta head cleaning pad

8. Resting mat

9. Carpet glider

10. Bottom cable tidy hook

11. Top cable tidy hook

12. Cable management clip

Assembly

Warning! Before attempting any of the following operations,

make sure that the appliance is switched off and unplugged

and that the appliance is cold and does not contain any water.

Attaching the handle (Fig. A)

u Slide the bottom end of the handle (4) into the top end

of the steam mop body (13) until it clicks into place. The

arrow on the handle (4) should be aligned with the top of

the steam mop body (13).

Attaching the steam head (Fig. B)

u Slide the bottom end of the steam mop body (13) onto the

steam head (5) until it clicks into place.

u The steam head can be removed from the Steam mop

body by pressing the steam head release button (14) and

pulling the steam mop body (13) off the steam head (5).

Attaching the water jug (Fig. C)

u Clip the water jug (3) onto the handle (4).

u Slide the water jug (3) down into the Steam mop body

(13), ensure that the water jug is rmly seated.

Attaching a cleaning pad (Fig. D)

Replacement cleaning pads are available from your Black &

Decker dealer:- (cat. no. FSMP20-XJ).

Steam head cleaning pad - cat. no. FSMP20-XJ).

Delta head cleaning pad - cat. no. FSMP30-XJ (FSM1630

Only).

u Place a cleaning pad (6 or 7) on the oor with the ‘hook &

loop’ side facing up.

u Lightly press the steam mop down onto the cleaning pad

(6 or 7).

Caution! Always place your steam mop on the resting mat (8)

with the handle (4) in the upright position when stationary and

make sure the steam mop is turned off when not in use.

Removing a cleaning pad (Fig. E)

Caution! Always wear suitable shoes when changing the

cleaning pad on your steam mop. Do not wear slippers or

open toed footwear.

u Return the handle (4) to the upright position and turn the

steam mop ‘OFF’.

u Place the steam mop on the resting mat and wait until it

cools down. (approximately ve minutes)

u Place the front of your shoe onto the cleaning pad removal

tab (15) and press down rmly.

u Lift the steam mop up off the cleaning pad.

Caution! Always place the steam mop on the resting mat (8)

with the handle (4) in the upright position when stationary and

make sure the steam mop is turned off when not in use.

Filling the water tank (Fig. F)

The watertank on your steam mop is removable for convi-

enient and easy lling.

This Steam Mop incorporates an anti-calc system to help

prolong the life of the system.

Note: Fill the water tank with clean tap water.

Note: In areas of very hard water, the use of de-ionised water

is recommended.

u Remove the water tank (3).

u Open the ller cap (19) by pressing the release button

(20).

u Fill the water tank (3) with water.

Warning! Your water tank has a 0.5 litre capacity. Do not over

ll the tank.

u Re-t the ller cap (19).

u Re-t the water tank (3).

Note: Ensure the ller cap is rmly secured.

Note: Do not use chemical cleaners with your steam mop..

Attaching the carpet glider (Fig. G) (For use on

carpets only)

u Place carpet glider on the oor.

u Attach a cleaning pad (6) to the unit.

u Lightly press the steam mop down onto the carpet glider

Black & Decker FSM1630 [4/12] Assembly
