6
ENGLISH
(Original instructions)
keep your cable out of the way of the work area.
u Always vacuum or sweep the oor before using the steam
mop.
u The easiest way to use the machine is to tilt the handle to
a 45˚ angle and clean slowly, covering a small area at a
time.
u Do not use chemical cleaners with your steam mop. To
remove stubborn stains from vinyl or linoleum oors, you
can use the steam burst button to apply extra steam to
the area or pre-treat with a mild detergent and some water
before using the steam mop.
Steam cleaning
u Place a cleaning pad (6 or 7) on the oor with the ‘hook &
loop’ side facing up.
u Raise the steam mop off the resting mat (8) and lightly
press it down onto the cleaning pad (6 or 7).
u Place the steam mop on the resting mat.
u Connect the steam mop to the mains.
u Press the ON/OFF button (1). It takes approximately 15
seconds for the steam mop to heat up.
u Press the Autoselect
TM
button (2) till the required setting is
reached.
u Pulling the handle (4) back will activate the steam pump.
After a few seconds steam will start to come out of the
steam head.
Note: When rst lled or after running dry it can take up to 45
seconds for steam to be produced.
u It takes a few seconds for steam to enter the cleaning pad.
The steam mop will now glide easily over the surface to be
sanitised/cleaned.
u Push and pull the steam mop slowly across the oor to
thoroughly steam clean each section.
Note: During use you may turn off the steam pump by return-
ing the handle to the upright position, this convenient feature
will allow you to place the steam mop on the resting mat for
a short time so that you may move items of furniture, then
continue cleaning without the need to switch the appliance off.
u When you have nished using the steam mop, return the
handle (4) to the upright position and turn it ‘OFF’, place it
on the resting mat (8) and wait until the steam mop cools
down. (approximately ve minutes)
Caution! It is important to monitor the water level in the water
tank. To rell the water tank and continue to sanitise/clean,
return the handle (4) to the upright position and turn the steam
mop ‘OFF’. Unplug the unit from the electrical wall outlet,
remove and rell the water tank (3).
Caution! Never leave the steam mop in one spot on any
surface for any period of time. Always place the steam mop on
the resting mat (8) with the handle (4) in the upright position
when stationary and make sure the steam mop is turned off
when not in use.
Carpet refreshing
u Place a cleaning pad (6) on the oor with the ‘hook & loop’
side facing up.
u Raise the steam mop off the resting mat (8) and lightly
press it down onto the cleaning pad (6).
u Place the carpet glider (9) on the oor.
u Lightly press the steam mop down onto the carpet glider
(9) until it clicks into place.
u Place the steam mop on the resting mat. (8)
u Connect the steam mop to the mains.
u Press the ON/OFF button (1). It takes approximately 15
seconds for the steam mop to heat up.
u Press the Autoselect
TM
button (2) to the Wood/Laminate
setting.
u Pulling the handle (4) back will activate the steam pump.
After a few seconds steam will start to come out of the
steam head.
Note: When rst lled or after running dry it can take up to 45
seconds for steam to be produced.
u Push and pull the steam mop slowly across the carpet to
thoroughly refresh each section.
Note: During use you may turn off the steam pump by return-
ing the handle (4) to the upright position, this convenient
feature will allow you to place the steam mop on the resting
mat (8) so that you may move items of furniture with out the
need to switch the appliance off.
u When you have nished using the steam mop, return the
handle (4) to the upright position and turn it ‘OFF’, place it
on the resting mat (8) and wait until the steam mop cools
down. (approximately ve minutes)
Caution! It is important to monitor the water level in the water
tank. To rell the water tank and continue to sanitise/clean,
return the handle (4) to the upright position and turn the steam
mop ‘OFF’. Unplug the unit from the electrical wall outlet,
remove and rell the water tank (3).
Caution! Never leave the steam mop in one spot on any
surface for any period of time. Always place the steam mop on
the resting mat (8) with the handle (4) in the upright position
when stationary and make sure the steam mop is turned off
when not in use.
After use (Fig. J & K)
u Return the handle (4) to the upright position and turn the
steam mop ‘OFF’,
u Place the steam mop on the resting mat (8) and wait until
the steam mop cools down. (approximately ve minutes)
u Unplug the steam mop from the electrical wall outlet.
u Empty the water tank (3).
u Remove the cleaning pad (6 or 7) and wash it ready for
