![Black & Decker FSM1630 [7/12] Troubleshooting](/views2/1083425/page7/bg7.png)
7
ENGLISH
(Original instructions)
next use. (Take care to follow the wash care instructions
printed on the cleaning pad).
u Wrap the supply cable around the cable tidy hooks (10 &
11).
Note: The top cable tidy hook (11) rotates to easily release the
cable ready for next use.
u Clip the supply cable onto itself using the cable tidy clip
(22) close to the plug.
u Place steam mop on the resting mat (8) for storage.
Note: With the handle (4) in the upright position, the cable
neatly wrapped around the cable tidy hooks (10 & 11) and
secured with the cable tidy clip (22) your steam mop will stand
on its own for storage. Alternatively there is a hanging bracket
(23) built into the hand grip (24) which will allow your steam
mop to be hung from a suitable hook on the wall. Always
ensure that your wall hook is capable of supporting the weight
of the steam mop safely.
Technical data
FSM1630
(Type 1)
Voltage V
ac
230
Power W
1600
Tank capacity ml
500
Weight kg 3.4
Troubleshooting
If your appliance seems not to operate properly, follow the
instructions below. If this does not solve the problem, please
contact your local Black & Decker repair agent.
Problem Step Possible solutions
The steam mop is
not turning on.
1
Check the unit is plugged in at the wall
socket.
2
Check the unit is switched on using the on/
off switch (1).
3 Check the fuse in the plug.
The digital controls
do not light up.
4
Check that the handle (4) of the steam mop
is pushed rmly into the steam mop body
(13). Check that the arrow on the handle is
ush with the top of the steam mop body
(13).
5 Check steps 1, then 2, then 3.
Problem Step Possible solutions
The steam mop is
not producing
steam.
6
The steam mop will only produce steam
once the handle is pulled back from the
upright position.
7
Check that the water tank (3) is full and
correctly tted.
NOTE: When rst lled or after running dry it
can take up to 45 seconds for steam to be
produced.
8
Check that the Steam head (5) is rmly
docked into the steam mop body (13).
9 Check steps 1, then 2, then 3.
The digital controls
go out during use.
10 Check steps 4, then 5, then 1, then 2, then 3
The steam mop
stops producing
steam during use.
11 Check steps 6, then 7, then 8, then 4, then 3.
The steam mop is
producing too
much steam during
use.
12
The steam mop has 3 settings. Press the
autoselect button (2) to reduce the amount of
steam being produced.
13
Check that the steam burst button (21) has
not been pressed.
The steam mop is
producing too little
steam during use.
14
The steam mop has 3 settings. Press the
autoselect button (2) to increase the amount
of steam being produced.
15
Press the steam burst button (21) to
temporarily increase the amount of steam.
Steam is escaping
from unexpected
areas of the unit.
16
Refer to the assembly chapter of the manual
for correct tting instructions of all parts and
accessories.
Where can I get
further information
/ accessories for
my steam mop.
17 www.blackanddecker.co.uk/steammop
www.blackanddecker.ie/steammop
