Panasonic CS-E12DKEW / CU-4E27CBPG [65/200] Indoor fan motor operation
![Panasonic CS-E12DKEW / CU-4E27CBPG [65/200] Indoor fan motor operation](/views2/1832475/page65/bg41.png)
9.3.1.7. Indoor Fan Motor Operation
A. Basic Rotation Speed (rpm)
•
• •
•
Required rotation speed for fan is set to respond to the remote control setting (10 rpm unit)
[Cooling, Dry, Fan]
Remote Control — — O O O O O — — —
Tab (rpm) PSHi SHi Hi Me+ Me Me- Lo Lo- SLo SSLo
CS-ME10DTEG 900 900 830 790 740 690 640 590 530 370
CS-E15DTEW 1070 1070 1000 940 870 800 730 680 630 370
CS-E18DTEW 1110 1110 1040 970 920 850 790 740 630 370
[Heating]
Remote Control — — O O O O O — — —
Tab (rpm) PSHi SHi Hi Me+ Me Me- Lo Lo- SLo SSLo
CS-ME10DTEG 900 900 830 780 730 680 630 590 530 370
CS-E15DTEW 1080 1080 1010 920 830 730 630 590 530 300
CS-E18DTEW 1110 1110 1050 950 860 770 680 630 540 370
65
CS-ME7DKEG CS-ME10DD3EG / CS-ME10DTEG CS-E15DB4EW
