Panasonic CS-E12DKEW / CU-4E27CBPG [79/200] Indoor fan motor operation

Panasonic CS-ME7DKEG / CU-2E18CBPG [79/200] Indoor fan motor operation

9.4.1.7. Indoor Fan Motor Operation

A. Basic Rotation Speed (rpm)

•

• •

•

Required rotation speed for fan is set to respond to the remote control setting (10 rpm unit)

[Cooling, Dry, Fan]

Remote Control — — O O O O O — — —

Tab (rpm) PSHi SHi Hi Me+ Me Me- Lo Lo- SLo SSLo

CS-E15DB4EW 600 600 560 520 480 440 400 350 310 200

CS-E18DB4EW 640 640 590 550 510 470 430 390 350 200

[Heating]

Remote Control — — O O O O O — — —

Tab (rpm) PSHi SHI Hi Me+ Me Me- Lo Lo- SLo SSLo

CS-E15DB4EW 650 650 600 570 540 510 480 460 300 300

CS-E18DB4EW 690 690 640 600 570 530 490 470 320 300

CS-ME7DKEG CS-ME10DD3EG / CS-ME10DTEG CS-E15DB4EW
