44
15.2. Sensible Capacity Chart
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 7.85 5.95 2.25 7.33 5.70 2.42 6.82 5.48 2.59 6.20 5.21 2.80
19.0°C 7.91 2.46
19.5°C 8.61 6.23 2.30 8.05 5.98 2.47 7.49 5.76 2.64 6.81 5.48 2.85
22.0°C 9.39 6.46 2.34 8.77 6.21 2.51 8.16 5.99 2.69 7.42 5.71 2.90
TC - Total Cooling Capacity (kW) Indoor 27°C/19°C
SHC - Sensible Heat Capacity (kW) Outdoor 35°C/24°C
IP - Input Power (kW)
