Introducing the Switch

Back of the Switch

DC power connector

HP 2530-8 Switch (J9783A)

HP 2530-8G Switch (J9777A)

HP 2530-8-PoE+ Switch (J9780A)

HP 2530-8G-PoE+ Switch (J9774A)

AC power connector

HP 2530-24 Switch (J9782A)

HP 2530-48 Switch (J9781A)

HP 2530-24G Switch (J9776A)

HP 2530-48G Switch (J9775A)

HP 2530-24-PoE+ Switch (J9779A)

HP 2530-24G-PoE+ Switch (J9773A)

AC power connector

HP 2530-48-PoE+ Switch (J9778A)

HP 2530-48G-PoE+ Switch (J9772A)
