Panasonic CU-L43DBE5 [4/113] Power supply

1.4. Operation range

1.4.1. Power Supply

The applicable voltage range for each unit is given in the following table. The working voltage among the three phases must be

balanced within a 3% deviation from each voltage at the compressor terminals. The starting voltage must be higher than 85% of

the rated voltage.

MODEL Unit Main Power Applicable Voltage

CU- Phase, Volts Hz Max Min

L34DBE5 1~240 50 264 216

L43DBE5 1~220 50 242 198

1~230 50 253 207

1.4.2. Indoor and Outdoor Temperature

•

• •

•

Model 50Hz CU-L34DBE5, CU-L43DBE5

Operating Hz Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)

Max Min Max Min

Cooling 50 32/23 21/15 43/- -15/-

Heating 50 27/- 16/- 24/18 -20/-

CS-F34DB4E5 CU-L34DBE5 / CS-F43DB4E5 CU-L43DBE5
