2.1.8. Piping and drainage
•
• •
•
Built-in upward draining mechanism.
2.1.9. Automatic changeover function (heat pump models)
•
• •
•
The unit automatically switches between cooling and heating in accordance with operating load in order to maintain a
comfortable indoor temperature.
2.1.10. Hot start system (heat pump models)
6
CS-F34DB4E5 CU-L34DBE5 / CS-F43DB4E5 CU-L43DBE5
