LG VLK9320W [19/37] Operation
![LG VLK9320W [19/37] Operation](/views2/1084134/page19/bg13.png)
19
Operation
Operation
Playing a tape
You will only be able to load and eject video cassettes
when your VCR is plugged into the mains.
Your VCR may also playback recordings from NTSC
tapes (on PAL TV).
Getting a better picture
When a cassette is inserted and playback started, the
automatic tracking function works to get the best possi-
ble picture automatically. If the quality of the recording is
poor, repeatedly press TRK + or - on the remote control
to manually adjust the tracking until any distortions have
been removed. Press numbered 0 on the remote control
to switch automatic tracking back on again.
1. Make sure that you have correctly connected your
VCR as described earlier in this book.
Turn on your TV.
Press POWER to turn on your VCR.
Insert the video cassette into your VCR.
The video cassette should have the window side
facing up and the arrow facing away from you.
2. Press N to start playing your tape.
If you load a video cassette which has had its
record protection tab removed, playback of the
cassette will start automatically.
AUTO TRACKING
Your VCR will automatically adjust the tracking to
give the best picture quality.
3. Press PAUSE/STEP to still a picture.
Press PAUSE/STEP repeatedly to advance the
tape frame by frame.
If you press FORWARD, the picture will be slowed
down at about 1/19 times the normal playback
Tapes can be paused for up to 5 minutes. After 5
minutes your VCR will stop the tape to prevent
damaging the tape or your VCR .
Still picture quality can be improved slightly by
pressing TRK + or -.
4. Press N to continue playing your tape.
Double speed playback
Press the "N (X2)" button during normal
playback. The tape will play back at double speed
and without sound.
Press the "N (X2)" button to return to playback at
normal speed
Picture search:
During playing back press either FORWARD or
BACKWARD and this will enable you to rapidly
wind the tape (7 times normal playback) and see
where you are on the tape.
Logic search:
During fast forwarding or rewinding press and hold
FORWARD or BACKWARD the picture will be
played back at 7 times normal playback speed.
5. Slow motion playback
, Shuttle :
During playing back or still picture press F or G.
You can reach the following playback speeds.
(REV, PB5-, PB1-, still, SLW, PLAY, 2PLY, CUE).
To switch off the slow motion and shuttle, press
the desired function.
During slow motion and shuttle, the noise bars
may appear on the picture according to the status
of tape. If distortions can be seen in the picture,
reduce them with TRK + or -.
6. Press STOP to end playback.
Press EJECT.
If the end of the tape is reached, your VCR will
stop playback automatically, rewind, stop, eject the
tape.
CM (Commercial Message) Skip:
This feature enables you during playback of a tape to
skip a commercial break in a few seconds, then
resume normal playback.
While tape is playing press CM SKIP on the remote
control to skip commercial (or another programme
material).
Repeatedly press CM SKIP to skip:
1 Press 30 seconds
2 Press 60 seconds
3 Press 90 seconds
4 Press 120 seconds
5 Press 150 seconds
6 Press 180 seconds
OPR (Optimum Picture Response)
This feature automatically improves playback picture
quality by adjusting your VCR to the condition of the
tape. Please note that the OPR icon ( ) will only
appear in play that mode when playing a tape.
1. Press i.
2. Press 1 or 2 to select OPR.
3. Press OK.
4. Press
33
or
44
repeatedly to select: OFF, SOFT or
SHARP.
Please note you may only set OPR when
playing a tape.
5. Press i return to screen.
SYS
12
SET
OSD
ON
OFF
OSD
f
R
OFF
SOFT
SHARP
