1. Function

The auto-cutter units are designed to cut various media such as labels, tickets

and tags precisely and accurately as the setting cut length.

2. Main specications of auto-cutter

 Cutting method: Guillotine cutter

 Maximum cut paper thickness: 0.25 mm (0.01”)

 Minimum cut paper length: 25.4 mm (1”)

 Cut paper width: Maximum: 118 mm (4.65”)

Minimum: 25.4 mm (1”)

 Durability:

Number of cuts:

Minimum 300,000 times

(for a paper thickness of 60 to less than 150 µm)

Minimum 100,000 times

(for a paper thickness of 150 to 250 µm)

Note

z Media with adhesive substance may be excluded from the number of cuts.

z The number of cuts can vary according to the quality of the paper.

 Media and paper types:

Roll or label (continuous, die-cut, fanfold, tag and ticket).

However, the following paper cannot be used:

z Paper with thickness of 0.06 mm (0.0024”) or less

z Roll paper with paper core diameter of 50 mm (2”) or less

Note

Using paper other than the specied types may cause problems such as

paper jams, so the paper specication must be checked before use.

 Cut accuracy:

z Cut length tolerance: ±1.0 mm or less

z Left and right cut tolerance: ±1.0 mm or less

Note

Cutting position can be adjusted using

printer commands (see page 12).

UTION

z When using adhesive media, dot not cut

labels itself. Adjust the printer to cut the

liner only. If label glue sticks to the cutter

blades, irregular cutting will occur.

Direction of paper feed

Left and right cut tolerance:

±1.0 mm or less

Cut length tolerance: ±1.0 mm or less
