THE TABLE OF CONTENTS
1. GENERAL OUTLINE .....................................................................14
1.1 Features ............................................................................................ 14
1.2 Unpacking .........................................................................................15
1.3 Model Classication ..........................................................................16
1.4 Basic Specications ..........................................................................17
2. EXPLANATION OF PRINTER PARTS ........................................... 19
2.1 Printer Appearance ...........................................................................19
2.2 Inner area of the top cover ................................................................22
2.3 Other Built-in Functions .....................................................................24
3. SETUP ............................................................................................ 26
3.1 Connecting the AC Power Cord .........................................................26
3.2 Serial Interface Board ........................................................................28
3.3 USB Interface .................................................................................... 29
3.4 Bluetooth Interface Board .................................................................. 30
3.5 Bluetooth USB host interface board .................................................. 33
3.6 Ethernet (LAN)/Wireless LAN Interface Board ..................................38
3.7 USB Power Supply Port ..................................................................... 44
3.8 Connecting the Cash Drawer ............................................................46
3.9 Precautions for Installing the Printer .................................................48
3.10 Adjusting the Paper Near-end Sensor .............................................49
3.11 Roll paper partition ..........................................................................50
3.12 Loading Paper .................................................................................52
3.13 Adjusting Media Sensor Positions ...................................................57
3.14 Selecting a Paper Type .................................................................... 59
3.15 Calibrating the Paper Sensor ..........................................................60
3.16 Precautions for Creating Applications and Practical Operations .....62
3.17 Download Site for Various Electronic Files ...................................... 62
4. MAINTENANCE AND TROUBLESHOOTING ...............................63
4.1 Periodic Cleaning ..............................................................................63
4.2 Clearing a Cutter Error ...................................................................... 64
4.3 Self Test .............................................................................................65
4.4 Hexadecimal Dump Printing .............................................................. 66
4.5 Error Indications ................................................................................67
4.6 Paper Jams .......................................................................................69
4.7 Precautions for Performing Printing for Which
Printing Speed Changes ................................................................... 69
