Citizen CT-S751 [12/67] The table of contents

——

THE TABLE OF CONTENTS

1. GENERAL OUTLINE .....................................................................13

1.1 Features ............................................................................................ 13

1.2 Unpacking .........................................................................................14

1.3 Model Classication ..........................................................................15

1.4 Basic Specications ..........................................................................15

2. EXPLANATION OF PRINTER PARTS ........................................... 17

2.1 Printer Appearance ...........................................................................17

2.2 Inside the Paper Cover ...................................................................... 19

2.3 Other Built-in Functions .....................................................................20

3. SETUP ............................................................................................ 22

3.1 Connecting the AC Power Cord .........................................................22

3.2 Serial Interface Board ........................................................................23

3.3 USB Interface .................................................................................... 24

3.4 Bluetooth Interface Board .................................................................. 25

3.5 Bluetooth USB host interface board .................................................. 28

3.6 Ethernet (LAN)/Wireless LAN Interface Board ..................................34

3.7 USB Power Supply Port ..................................................................... 40

3.8 Connecting the Cash Drawer ............................................................42

3.9 Precautions for Installing the Printer .................................................44

3.10 Adjusting the Paper Near-end Sensor .............................................45

3.11 Loading Paper .................................................................................46

3.12 58-mm Width Roll Paper Partition ................................................... 48

3.13 Mounting the Cable Cover ............................................................... 49

3.14 Precautions for Creating Applications and Practical Operations .....50

3.15 Download Site for Various Electronic Files ...................................... 50

4. MAINTENANCE AND TROUBLESHOOTING ...............................51

4.1 Periodic Cleaning ..............................................................................51

4.2 Clearing a Cutter Error ...................................................................... 52

4.3 Self Test .............................................................................................53

4.4 Hexadecimal Dump Printing .............................................................. 54

4.5 Error Indications ................................................................................55

4.6 Paper Jams .......................................................................................57

4.7 Precautions for Performing Printing for Which

Printing Speed Changes ................................................................... 57

5. OTHER ...........................................................................................58

5.1 External Views and Dimensions ........................................................ 58

5.2 Printing Paper .................................................................................... 59

5.3 Manual Setting of Memory Switches ................................................. 60
