LG E2341V [18/28] On screen display osd selection and adjustment
![LG E2341V [18/28] On screen display osd selection and adjustment](/views2/1084621/page18/bg12.png)
Saving Data depends on the Panel. So, those values should be different from each
panel and panel vendor.
LG accumulate those values using integrated function with 10 minutes broadcast v-
ideo signal.
LED Saving means that how much power can be saved using WLED Panel instead
of CCFL panel.
SUPER Saving means that how much power can be more saved using SUPER E-
NERGY SAVING function.
17
22 inch 23 inch 24 inch
SAVING DATA(W/h) :
