Installing the Wall mount plate
This monitor satisfies the specifications of the Wall mount plate
or the interchange device.
1. Place the monitor face down on the soft cloth.
2. To disconnect the Stand Base from the Stand Body, unfold the screw handle and
turn it to the left.
3.
Pull out the Stand Base to remove.
