LG W2363V [6/31] Connecting and disassembling the stand
![LG W2363V [6/31] Connecting and disassembling the stand](/views2/1084654/page6/bg6.png)
5
Connecting the Display
Before setting up the monitor, ensure that the power to the monitor,
the computer system, and other attached devices is turned off.
Connecting and Disassembling the stand
1. Place the monitor face down on the soft cloth.
2. Assemble the Stand Base into the Stand Body in the correct direction.
Make sure you push the Stand Base until the end.
Stand Base
Stand Body
The Stand Base may
fall and get damaged
or cause injury.
Good Connection
Bad Connection
