ENG
НЕРА-фильтр
Префильтр
1. The battery of the cordless vacuum cleaner can be charged in two ways:
• During charging, install the vacuum cleaner correctly in the hanger
and connect the power adapter to the battery.
• The battery can be removed from the device and charged via the AC adapter
at any convenient location.
2. The plug of the power adapter is inserted into the corresponding hole in the battery.
3. The battery charging time is 4-5 hours. When charging is in progress, the battery
indicator flashes. After the battery is fully charged, the indicator lights up continuously
without blinking.
Note:
Use the supplied adapter to charge the battery.
Please charge the battery fully before using it for the first time.
You cannot use the vacuum cleaner while charging.
Warning! Do not leave the battery unattended while charging; after the battery is fully
charged, disconnect it from the charger.
• Flat nozzle
• Attachment with rotating brush head
• Washing nozzle Aqua Drive
1. Select the desired hard-to-reach
attachment and attach it directly
to the suction port of the dust container.
To increase the cleaning space, if necessary,
fix the desired accessory to the metal bar.
2. The 2-in-1 flat nozzle has two working
positions.
To change the position of the nozzle,
simply press the button located on the
nozzle and slide the brush.
3. To use the wahing nozzle, secure washable
mops to the turntable. Pour water or water
with detergent into the water tank. Place
the water tank on the motorized nozzle. To
start wet cleaning, set the valve to the «ON»
position. After using the attachment, wash
and dry the washable mops and water tank.
Using attachments
1. Fix the hanger on the wall with expansion
screw.
2. Align the bottom of the vacuum cleaner
case with the protruding notch on the
bracket so that they are parallel to each
other.
3. Slide the case down.
Affixing the device
After each cleaning, clean the tank of dirt
and dust. Check the position of the air outlet
valve.
Press the upper end of the catch at the
bottom of the dust tank, and the bottom
of the dust tank will automatically open.
Collected dirt should not exceed the MAX mark.
After using the vacuum cleaner, it is
recommended to clean the dust tank and
clean the brush if it gets clogged. A full dust
tank will significantly reduce the efficiency
of the vacuum cleaner.
1. Disconnect the dust container from
the case of the vacuum cleaner, then
sequentially remove all filtration elements
from it - the HEPA filter and the capacitive
pre-filter.
2. Rinse the HEPA filter and prefilter
under running water and dry at room
temperature. Use the optional HEPA filter
included in the kit. You can purchase
an additional filter if necessary.
3. Place the filtration system elements back
into the dust tank. When installing the
pre-filter, align the grooves of the body
and the filter. To install the HEPA filter,
turn it clockwise until it fits into the slots
of the pre-filter.
1. Remove the roller brush retainer from
the underside of the motorized accessory,
then remove the roller brush.
2. Remove hair and other debris from
the roller brush and clean the brush inlet.
3. Place the clean brush back into
the motorized accessory and reinstall
the retaining parts.
Easy cleaning of the dust tank
Cleaning the vacuum cleaner
Cleaning the motorized floor brush
Кнопка
сброса
мусора
Клапан
воздухоотвода
Dust release
button
Air outlet valve
НЕРА-filter
Pre-filter
Removable water
tank
Washing nozzle
Washable mops
Water supply valve
ON
OFF
