Specifications W2286L
21.995 inches (55.8673 cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size : 55.8673 cm
0.282 x 0.282 mm (Pixel Pitch)
Display
Horizontal Freq. 30 - 83 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate Sync.
SOG (Sync On Green), Digital
Sync Input
Signal Input 15 pin D-Sub Connector (Analog)
DVI-D Connector (Digital)
HDMI Connector (Digital)
Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital, HDMI
Video Input
Max VESA 1680 x 1050 @ 60 Hz
Recommend VESA 1680 x 1050 @ 60 Hz
Resolution
Plug&Play
On Mode : 27 W(Typ.)
Sleep Mode ≤ 1 W
Off Mode ≤ 1 W
Power
Consumption
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environmental
Conditions
With Stand
Width 51.97 cm / 20.46 inches
Height 43.73 cm / 17.22 inches
Depth 19.84 cm / 7.81 inches
Weight(excl. packing) 4.1 kg (9.04 lbs)
Dimensions
& Weight
Tilt : -2˚~15˚
Range
12V 2.0A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B
Without Stand
Width 51.97 cm / 20.46 inches
Height 42.57 cm / 16.76 inches
Depth 8.46 cm / 3.33 inches
NOTE
Information in this document is subject to change without notice.
Lien Chang, LCAP07F
AC-DC Adapter
