LG W2286L [7/33] Screw turn the screw by using the screw handle

Connecting the Display

IMPORTANT

This picture depicts the general model of connection. Your monitor may differ from the items

shown in the picture.

Do not carry the product upside down holding only the stand base. The product may fall and

get damaged or cause injury.

4. Then fold the screw handle flat. 5. Once assembled take the monitor up

carefully and face the front side.

6. To disconnect the Stand Base from the Stand Body, unfold the screw handle and

turn it to the left.

3. Turn the screw to the right to fix the Stand Body to the Stand Base.

Screw

Turn the screw

by using the

screw handle.
