LG 23CAV42K-BL [24/48] Product specification

ENG

English

Specications

PRODUCT SPECIFICATION

LCD Screen Type 58.42 cm (23 inch) TFT (Thin Film Transistor)

LCD (Liquid Crystal Display) Screen

Diagonal length of the screen: 58.42 cm

Pixel Pitch 0.2652 mm x 0.2652 mm

Resolution Maximum Resolution 1920 x 1080 @ 60 Hz

Recommended Resolution 1920 x 1080 @ 60 Hz

DVI-I output 1920 x 1200 @ 60 Hz

Video Signal Horizontal Frequency 30 kHz to 68 kHz

Vertical Frequency 57 Hz to 63 Hz

Synchronization Separate Sync

Input Connector 15-pin D-SUB (Analog)

Power 19 V 2.3 A

Power Consumption(Typ.)

(D-sub/CLOUD)

On Mode: 24 W(D-sub) / 29 W(CLOUD)

Power Saving Mode ≤ 0.5 W (CLOUD mode: 7 W)

Off Mode ≤ 0.5 W

Dimension/

Weight

Monitor Size (Width x Height x Depth)

With Stand 544.2 mm x 386.5 mm x 130.6 mm

Without Stand 544.2 mm x 332.3 mm x 47 mm

Weight (Without

Packaging)

5.54 kg

AC/DC Adapter Type PA-1650-68, manufactured by LITE-ON TECHNOLOGY CORPORATION.

OUTPUT: 19 V 3.42 A

Stand Angle

Adjustment

Forwards/Backwards: -5° to 15° (Monitor)

Environment

Condition

Operating Condition Temperature: 10°C to 35°C; Humidity: 10% to 80%

Storing Condition Temperature: -20°C to 60°C; Humidity: 5% to 90%

The specifications are subject to change without notice.
