LG 23CAV42K-BL [27/48] Using cloud solution

ENG

English

Using CLOUD Solution

USING CLOUD SOLUTION

If the network is not properly connected (e.g., dur-

ing portal boot up), or connection is being created,

the "Network connection lost. Waiting for connec-

tion …" message is displayed on the Connection

screen.

Figure 2-2 shows the message displayed when the

network is not ready.

If the network is connected and IP is being ac-

quired, the message "Network connection detect-

ed. Acquiring IP address …" is displayed on the

Connection screen. Figure 2-3 shows the message

displayed when the network is ready and the IP is

being acquired.

<Figure 2-3 Acquiring the IP after Network Con-

nected>

The below is the Connection screen displayed

when network is completely ready.

Connect Screen

The Connect screen is shown during start-up,

except when the portal has been configured for a

managed start-up or auto-reconnect. The logo dis-

played above the Connect button can be changed

by uploading a replacement image via the admin

interface.

Menus and functions in CLOUD mode may

be slightly different depending on the firmware

version. You can download the user manual

for each version from the Teradici homepage:

http://www.teradici.com

To check the firmware version, See p.44 .

NOTE
