Hyundai H-1407 [4/14] Cassette recorder operation
![Hyundai H-1407 [4/14] Cassette recorder operation](/views2/1008572/page4/bg4.png)
4
Radio operation
· Set FUNCTION switch to RADIO position.
· Select your desired broadcasting band with BAND switch.
· Rotate the TUNING control regulator to receive the desired broadcast.
· Adjust the level and quality of sound with VOLUME control regulator.
· To turn off the radio, set the FUNCTION switch to TAPE position.
Antenna
· For FM reception, adjust the telescopic antenna appropriately to obtain the best reception on the band selected.
· The AM signal is picked up through the built-in ferrite antenna. The set should be placed to a position for the best reception.
Cassette recorder operation
Cassette playback
· Slide the FUNCTION switch to TAPE position.
· Press the STOP/EJECT button to open the cassette compartment.
· Insert a cassette and push the cassette door to close the cassette compartment.
· Press the PLAY button to start the playing.
· Press the PAUSE button to pause the playing.
· Press the STOP/EJECT button to stop the playing, press the button again to open the cassette door and you can take out the tape.
· When the tape plays to the end, playing will be stopped automatically.
· Press the "STOP" button followed by the "REWIND" or "FAST-FORWARD" button to rewind or forward the tape at high speed.
Insertion & removal of discs
· When opening the CD-door, always ensure the disc is not in motion (not spinning) when you open the CD-door. Always press "STOP" button to stop
the disc spinning first.
· Place a CD into the compartment with the label-side (printed side of disc) facing upwards. Press down in the center part of disc until the disc "locks"
onto the center spindle.
· When the CD has been placed onto the center spindle, gently lower the CD-door downwards until it locks shut.
· The CD is now ready to be played.
· To remove a disc, follow the same procedure as described above, except to remove the CD instead of inserting it into the compartment, by placing
one finger at the middle of disc (center spindle) & the other at the edge of the disc & gently pulling upwards.
· Important : always hold a CD by its edges. Avoid getting any finger prints, smudges or dirt onto the surface of a disc. In case this happens, use a
special CD-cleaning cloth or cleaning kit to remove the dirt or smudges.
