Hyundai H-1407 [7/14] Specification

Recording from CD

· Set FUNCTION switch to CD position.

· Insert your cassette tape in the cassette compartment.

· Activate the CD player.

· Press RECORD and PLAY buttons simultaneously to start recording.

· To stop recording temporarily, press the PAUSE button. To continue recording, press the PAUSE button again.

· Press STOP/EJECT button when finished. Then stop CD playback by pressing the CD STOP button of the CD player.

· You may want to monitor during recording. You can adjust the sound with VOLUME control regulator. These adjustments do not affect the content of

recording.

Maintenance and care

· Check your batteries regularly, old or discharged batteries should be replaced. If the unit is not going to be used for some time or

is being run exclusively on the alternative power, remove the batteries to avoid leakage and damage.

· Electronic products of this kind should never be subjected to moisture or extreme temperatures.

· If necessary, clean the unit with a piece of cloth dampened with water only (be sure the AC power cord is disconnected from the

power supply).

· The heads and capstan are in constant contact with the moving tape. Use a small cotton bud with alcohol or special tape head cleaner to

clean these parts. Never touch the heads with anything metallic.

Erase protection

· To prevent accidental erasing of a cassette, simply break off the two plastic tabs located on the cassette tapes rear side.

· When a cassette with removed plastic tabs is inserted, the recording button cannot be pressed.

· If a cassette is to be erased and re-recorded at a later stage, simply cover the holes on the cassette where the tabs were removed, with a

piece of strong adhesive tape.

CD protection

· When pick up the CD disc, always hold the edge of the disc, never touch the surface of the disc, it would scratch the disc surface and

may occur sound distortion or raise reading problem.

Specification

Power supply 230 V, 50 Hz

RMS 2.5 W x 2

Net / Gross Weight 2.16 kg / 2.61 kg

Gift box dimension (L x W x H) 272 mm x 281 mm x 178 mm
