LG CordZero A9N-Core [18/133] Wall mounted installation

Anchor the charging station to the wall with the

stand anchoring screw j.

Plug the power cord into the power outlet.

Use double-sided tape

Use double-sided tape to attach the wall anchoring

block a to the charging station and the wall.

• Do not use double-sided tape on wallpaper.

• Remove the center section of double-sided

tape. Attach the wall anchoring block to the

charging station by using the tape.

• Attach the second piece of double-sided tape

to the other side of the wall anchoring block,

and use it to temporarily anchor the charging

station to the wall in the desired location.

Wall-Mounted Installation

For wall-mounted installations, the charging station

must be attached securely to the wall using the

provided (short) wall anchoring screws.

Connect the power adapter to the port on the

back of the charging station.

Before drilling, make sure that there are no

pipes or electrical wires inside the wall at the

desired location.

Hold the charging station at least 1 m from the

floor and near enough to easily reach a power

outlet. Mark the positions of the screw holes

on the wall.

Drill 2 holes at the marked positions and insert

the drywall anchor.

• Before drilling, make sure that there are no

pipes or electrical wires inside the wall at

the desired location.

• For drywall anchor: use 6.5 mm drill bit

• Recommended diameter of hole: 6.5 mm

• Recommended depth: 60 mm

• If screwing into drywall, the drywall anchor

should be used.
