06 GB

2.3. ADAPTING THE HOB TO DIFFERENT

TYPES OF GAS

To adapt the Hob for use with different types of gas, carry out the

following instructions:

•remove the grids and burners

•insert on hexagonal spanner (7 mm) into the burner support (Figure

•Unscrew the injector and replace it with one suitable for the gas to be

used (see gas type table)

1)As illustrated, assemble parts in sequence:

A: 1/2 Male Adaptor Cylindirical

B: 1/2 Seal

C: 1/2 Female Gas Adaptor Conical-Cylindirical or

Cylindirical-Cylindirical

2)Tighten the joints with the spanner, remembering to twist the

pipes into position.

3)Attach fitting C to mains gas supply using rigid copper pipe or

flexible steel pipe.

IMPORTANT: carry out a final check for leaks on the pipe

connections using a soapy solution. NEVER USE A FLAME. Also,

make sure that the flexible pipe cannot come into contact with a

moving part of the cabinet (eg.adrawer) and that it is not situated

where it could be damaged.

Warning: If gas can be smelt in the vicinity of this appliance turn off the

gas supply to the appliance and call the engineer directly. Do not

search for a leak with a naked flame.

2.4. REGULATING THE MINIMUM FLAME

After lighting the burners, turn the control knob to the minimum setting

and then remove the knob (this can easily be removed by applying

gentle pressure).

Using a small «Terminal» type screwdriver the regulating screw can

be adjusted as in Figure 9. Turning the screw clockwise reduces the

gas flow, whilst turning it anticlockwise increases the flow – Use this

adjustment to obtain a flame of approximately 3 to 4 mm in length and

then replace the control knob.

When the gas supply available is LPG - the screw to set the idle flame

must be turned (clockwise) to the end stop.

When you have carried out the new gas regulation, replace the old gas

rating plate on your appliance with one (supplied with hob) suitable for

the type of gas for which it has been regulated.

3. USE OF HOB - USER INSTRUCTIONS

This appliance must only be used for the purpose for which it is

intended, domestic cooking, and any other use will be considered

improper and could therefore be dangerous. The Manufacturer will

not be responsible for any damage or loss resulting from improper

use.

3.1. USING THE GAS BURNER

To ignite the burners, place a lighted taper close to the burner, press in

and turn the control knob anti-clockwise.

If the burners have not been used for a couple of days, wait for a few

seconds before lighting the burner, this will allow any air present in the

pipes to escape.

For appliances fitted with electronic ignition carry out the following:

• push in and turn the knob anticlockwise to the ignition symbol.

• ignite the burner by pressing the sparker button.

For hobs fitted with automatic ignition simply push in and turn the knob

to the ignition symbol.

The ignition system will continue to generate sparks as long as the

control knob is being pressed.

If the burner has not ignited within 5 seconds, turn the knob to the 0

position and repeat the operation.

For smaller containers the gas burner should be regulated so that the

flame does not overlap the base of the pan. Vessels with a concave or

convex base should not be used.

WARNING: If a flame is accidentally extinguished, turn the knob

to the off position and do not attempt to re-ignite if for at least 1

minute.

If over the years the gas taps become stiff to turn it is necessary to

lubricate them.

Such operation must be carried out only by qualified Service

Engineers.

The flexible tube shall be fitted in such a way that it cannot come into

contact with a moveable part of the housing unit (e.g. a drawer) and

does not pass through any space where it may become crushed/

kinked or damaged in any way.

To prevent any potential damage to the hob please carry out the

installation following this sequence (picture 6):

For models fitted with a safety tap (which cuts-off the flow of gas if the

flame is accidentally extinguished) the burners are ignited and

described above, but care must be taken.

Prior to switching on the gas hob ensure that the burners and burner

caps are correctly placed within their position.

GENERAL ADVISE

For best results, use cooking vessels with a flat surface. The size of

the surface should match the gas burner side as follows. Table A.

Suitability of Cooking Pans

Keep in mind that larger pans have larger heating surfaces.

This will help them to cook the food faster than pans with smaller heating

surfaces.

Always use pan sizes proportionate to the amount of the food to be

cooked. In order to prevent splashing, do not use very small pans,

especially for foods with excess liquid. If you use excessively large pans

for quick cooked foods, sausages and liquids will stick and residues will

remain attached to the pan after being emptied.

Closed pans and baking trays or moulds are suggested for cooking

sweets. Splashed sugar and juices from an open pan may stick to the

cooker surface and will be difficult to remove.

This is especially important for pans used for roasting or pressurized

cooking at high temperature.

Do not leave burners unattended without a pan or with an empty pan on

top.

Check the suitability of cooking pans with respect to the following criteria;

They should be heavy.

They should completely cover the burner surface; they may be a little

bigger but no smaller.

Base surfaces should be completely flat and fit well on the cooking

surface.

•For the best use of the electric hotplates and to minimize energy

consumption, only pans with smooth flat bases should be used. The size of

the pan should be as close as possible to the diameter of the hotplate, and

never smaller. The base of the pan should be dry and spillage should be

avoided. Empty pans must not be left on the plates, and the plates should

not be left switched on without a pan.

(Figure 11)

Turn the knob to the position for the required temperature of the hot plate.

The indicator light of the hot plate will come on and the hot plate will start to

heat.

When cooking is completed, turn the knob to the “ O” position. (Figure 10).

Do not leave the hot plate turned on without a pan on it. The diameter and

the base of the pan you use is critical. The maximum diameter of the pan

base is 14 cm and the base should be flat.

Leave the hot plate to heat up for 5 minutes before placing a pan on it the

first time you use it. This will allow the heat resistant coating of the plate to

harden due to burning.

Use a wet cloth and detergent for cleaning the hot plates. Do not remove

food residues from the hot plates with a knife or any other hard, sharp

object.

Turn on the hot plate for a few moments to dry it after cleaning. However, it

must never be left on for more than a few moments without a pan on top.

Position

Power (Watt)

Explanation

100 W

180 W

250 W

500 W

750 W

1000 W

135 W

220 W

300 W

850 W

1150 W

1500 W

Off

Heating

Cooking at low temperature

Cooking, Roasting, Boiling

3.2. USE OF COOKTOP ELECTRICAL PLATES

Table A

Auxiliary

Semi Rapid

Rapid

Burner Type

Ø pan / pot

Max(cm)

AUX

4 crown

Ø pan / pot

Mın (cm)
