![Omron NYB1E-313E1 [217/276] Appendices](/views2/1872506/page217/bgd9.png)
Item Default / Remark
PCH-FW Configuration Comms Hub Support Disabled
JHI Support Disabled
Core Bios Done Message Enabled
Firmware Update Con-
figuration
Me FW Image Re-Flash Disabled
PTT Configuration TPM Device Selection dTPM
ME Debug Configura-
tion
HECI Timeouts Enabled
Force ME DID Init Status Disabled
CPU Replaced Polling Disable Disabled
ME DID Message Enabled
HECI Retry Disable Disabled
HECI Message check Disable Disabled
MBP HOB Skip Disabled
HECI2 Interface Communication Disabled
KT Device Enabled
IDER Device Enabled
End Of Post Message Send in DXE
DOI3 Setting for HECI Disable Disabled
Thermal Configuration CPU Thermal Configu-
ration
DTS SMM Disabled
Tcc Activation Offset 0
Tcc Offset Time Window Disabled
Tcc Offset Clamp Enable Disabled
Tcc Offset Lock Enable Disabled
Bi-directional PROCHOT# Enabled
Disable PROCHOT# Output Enabled
Disable VR Thermal Alert Disabled
PROCHOT Response Disabled
PROCHOT Lock Disabled
ACPI T-States Disabled
PECI Reset Disabled
PECI C10 Reset Disabled
Platform Thermal Con-
figuration
PCH Thermal Device Enabled in PCI mode
PCH Temp Read Enabled
CPU Energy Read Enabled
CPU Temp Read Enabled
Alert Enable Lock Disabled
DPTF Configuration DPTF Disabled
Intel ICC ICC/OC Watchdog Timer Disabled
Watchdog POST Watchdog Disabled
Runtime Watchdog Disabled
Appendices
A-17
NY-series Industrial Box PC Hardware User's Manual (W553)
