NY£2A
Intel
®
Atom
®
x5-E3940
CPU Specifications
CPU specifications for an Intel
®
Atom
®
x5-E3940 CPU.
Item Specifications
Cores / Threads 4 / 4
CPU base frequency 1.6 GHz
Maximum turbo frequency 1.8 Ghz
Cache 2 MB
Cooling details Passive cooling (fanless)
Graphics controller Intel ® HD Graphics 500
DDR type DDR3L-1866, non-ECC
NY£2C Intel
®
Celeron
®
3965U CPU Specifications
CPU specifications for an Intel
®
Celeron
®
3965U CPU.
Item Specifications
Cores / Threads 2 / 2
CPU base frequency 2.2 GHz
Maximum turbo frequency ---
Cache 2 MB
Cooling details Passive cooling (fanless)
Graphics controller Intel ® HD Graphics 610
DDR type DDR4-2400, non-ECC
NY£25 Intel
®
Core
™
i5-4300U CPU Specifications
CPU specifications for an Intel
®
Core
™
i5-4300U CPU.
Item Specifications
Cores / Threads 2 / 4
CPU base frequency 1.9 GHz
Maximum turbo frequency 2.9 GHz
Cache 3 MB
Cooling details Passive cooling (fanless)
Graphics controller Intel ® HD Graphics 4400
DDR type DDR3L-1600, non-ECC
4 Specifications
4-7
NY-series Industrial Box PC Hardware User's Manual (W553)
4-1 General Specifications
4
4-1-5 CPU Specifications
