Omron NYB1E-C13C6 Руководство пользователя онлайн
Industrial PC Platform
NY-series
Industrial Box PC
Hardware User's Manual
NYB££-
££0
NYB££-££1
NYB££-££2
NYB££-££3
NYB££-££4
Industrial Box PC
W553-E2-13
Содержание
- Hardware user s manual 1
- Industrial box pc 1
- Industrial pc platform 1
- Ny series 1
- Ny series industrial box pc hardware user s manual 1
- Copyrights 2
- Trademarks 2
- Additional information 3
- Applicable products 3
- Intended audience 3
- Introduction 3
- Refer to 1 4 product configuration box pc on page 1 5 for configuration details 3
- Thank you for purchasing the industrial box pc this manual contains information that is necessary to use the industrial box pc hereafter also named box pc please read this manual and make sure you understand the functionality and performance of the box pc before attempting to use it keep this manual in a safe place where it will be available for reference during operation 3
- This manual covers following industrial box pc products 3
- This manual is intended for the following personnel who must also have knowledge of electrical sys tems an electrical engineer or the equivalent personnel in charge of introducing factory automation systems personnel in charge of designing factory automation systems personnel in charge of installing and maintaining factory automation systems personnel in charge of managing factory automation systems and facilities 3
- Sections in this manual 5
- Contents 6
- Introduction 1 6
- Manual information 9 6
- Precautions for correct use 21 6
- Precautions for safe use 18 6
- Regulations and standards 23 6
- Related manuals 25 6
- Revision history 29 6
- Safety precautions 14 6
- Sections in this manual 3 6
- Terminology and abbreviations 27 6
- Terms and conditions agreement 11 6
- 1 configuration for nyb and nyp 2 7
- 1 intended use 2 7
- 1 layers and components 3 7
- 10 optional hardware 22 7
- 2 hardware features 3 7
- 2 led indicators 7 7
- 3 id information label 4 7
- 3 power button 9 7
- 4 connectors 10 7
- 4 product configuration box pc 5 7
- 5 overall setup procedure 7 7
- 5 sd memory card slot 16 7
- 6 cfast card slot optional 17 7
- 6 industrial pc platform overview 8 7
- 7 drive bays 18 7
- 8 pcie card slot 19 7
- 9 spare parts 20 7
- Contents 7
- Section 1 overview 7
- Section 2 system configurations 7
- Section 3 hardware 7
- 1 general specifications 2 8
- 1 unpack 2 8
- 2 connector specifications 19 8
- 2 install options 5 8
- 3 environmental specifications 31 8
- 3 mount 16 8
- 4 wire 28 8
- Contents 8
- Section 4 specifications 8
- Section 5 installation 8
- 1 power on 2 9
- 1 preventive maintenance 2 9
- 2 corrective maintenance 4 9
- 2 power off 3 9
- 3 react to product messages 5 9
- 4 react to windows messages 6 9
- 5 connect 42 9
- 6 initial power on 45 9
- 7 install software 49 9
- 8 connect ups 50 9
- 9 create backup and repair data 56 9
- A 1 bios a 2 9
- A 2 dvi connector pin details a 67 9
- A 3 rs 232c connector pin details a 70 9
- Appendices 9
- Contents 9
- Section 6 operating procedures 9
- Section 7 maintenance 9
- 1 unpack 11
- Manual information 11
- Page structure 11
- Manual information 12
- Special information 12
- Buyer remedy 13
- Exclusive warranty 13
- Limitations 13
- Terms and conditions agreement 13
- Warranties 13
- Warranty limitations of liability 13
- Application considerations 14
- Limitation on liability etc 14
- Programmable products 14
- Suitability of use 14
- Terms and conditions agreement 14
- Change in specifications 15
- Disclaimers 15
- Errors and omissions 15
- Performance data 15
- Terms and conditions agreement 15
- Caution 16
- Definition of precautionary information 16
- Indicates a potentially hazardous situation which if not avoid ed could result in death or serious injury additionally there may be severe property damage 16
- Indicates a potentially hazardous situation which if not avoid ed may result in minor or moderate injury or property damage 16
- Safety precautions 16
- Symbols 16
- The following notation is used in this manual to provide precautions required to ensure safe usage of the industrial box pc the safety precautions that are provided are extremely important to safety always read and heed the information provided in all safety precautions the following notation is used 16
- Warning 16
- Disassembly and dropping 17
- Fail safe measures 17
- Installation 17
- Safety precautions 17
- Warning 17
- Warnings 17
- Actual operation 18
- Safety precautions 18
- Caution 19
- Cautions 19
- Installation 19
- Safety precautions 19
- Wiring 19
- Disassembly dropping mounting installation and storage 20
- Precautions for safe use 20
- Wiring 20
- Actual operation 21
- Operation 21
- Power supply design and turning on off the power supply 21
- Precautions for safe use 21
- Battery and fan replacement 22
- Cleaning maintenance and disposal 22
- General communications 22
- Precautions for safe use 22
- Precautions for correct use 23
- Storage installation and mounting 23
- Wiring 23
- Actual operation and operation 24
- Battery replacement 24
- Precautions for correct use 24
- Sd memory cards 24
- Applicable directive 25
- Conformance to eu directives 25
- Emc directive 25
- Regulations and standards 25
- Conformance to kc certification 26
- Conformance to ul and csa standards 26
- Regulations and standards 26
- Software licenses and copyrights 26
- Related box pc manual 27
- Related manuals 27
- Related products manuals 27
- The following manuals are related use these manuals for reference 27
- Industrial monitor manual 28
- Related manuals 28
- This table contains the related manual of the industrial monitor 28
- Hardware 29
- Industrial pc platform 29
- Terminology and abbreviations 29
- Software 30
- Terminology and abbreviations 30
- Cat no 31
- Revision history 31
- W553 e2 13 31
- Revision history 32
- Overview 33
- Section 1 overview 33
- 1 intended use 34
- Overview 34
- 2 hardware features 35
- Overview 35
- 3 id information label 36
- Additional information 36
- Overview 36
- Refer to 3 1 2 base layer on page 3 5 for the id label location 36
- The id information label contains relevant information about the industrial box pc the following example will be different from your product label 36
- 4 product configuration box pc 37
- Overview 37
- The structure of the model id is nyb each item in the model id has a specific meaning 37
- This section provides an overview of the product configurations available for the industrial box pc the product configuration is visible in the model id that is mentioned on the id information label of the product 37
- Overview 38
- 5 overall setup procedure 39
- Overview 39
- 6 1 industrial monitor 40
- 6 industrial pc platform overview 40
- Overview 40
- 6 2 industrial box pc 41
- 6 3 industrial panel pc 41
- Overview 41
- Section 2 system configurations 43
- System configurations 43
- 1 configuration for nyb and nyp 44
- Additional information 44
- Base layer expansion layer 44
- Refer to 3 1 layers and components on page 3 3 for details refer to ny series operating systems and software utilities manual cat no w616 for de tails on the operating system the support software and the apis 44
- System configurations 44
- The industrial pc supports the following hardware configurations 44
- The major parts for configurations are layers all configurations have the base layer and a cooling layer the base layer contains the cpu the software and most of the connectors and functionality the optional expansion layer supports pcie cards and storage devices a display layer is always present for an industrial panel pc 44
- 1 layers and components 3 45
- 10 optional hardware 22 45
- 2 led indicators 7 45
- 3 power button 9 45
- 4 connectors 10 45
- 5 sd memory card slot 16 45
- 6 cfast card slot optional 17 45
- 7 drive bays 18 45
- 8 pcie card slot 19 45
- 9 spare parts 20 45
- Hardware 45
- Section 3 hardware 45
- This section provides an overview of the hardware of the industrial box pc 45
- Hardware 46
- 1 layers and components 47
- Hardware 47
- This section shows the layers of the industrial box pc 47
- 1 1 cooling layer 48
- Hardware 48
- This section gives details on the cooling layer the cooling layer will dissipate excessive heat from the box pc thickness and design details of the cooling layer can vary depending on the product configuration 48
- 1 2 base layer 49
- Hardware 49
- The connector layout and the available components can differ depending on the product configuration refer to 1 4 product configuration box pc on page 1 5 for configuration details 49
- This section shows the component names and functions for the base layer the base layer houses most of the functionality of the box pc 49
- 1 3 expansion layer optional 50
- Hardware 50
- Nyp 1 refer to 1 4 product configuration box pc on page 1 5 for model details 50
- This section shows the component names and functions for the expansion layer the expansion layer adds additional functionality to the base layer the expansion layer is available for models 50
- 2 1 pwr led indicator 51
- 2 led indicators 51
- Hardware 51
- The industrial box pc has led indicators located at the base layer these led indicators provide the current operating status of the box pc models with an expansion layer have a second row with four led indicators that have the same func tion the following led indicators are available 51
- The power led pwr indicates the operating mode of the box pc 51
- 2 2 err led indicator 52
- 2 3 hdd led indicator 52
- 2 4 run led indicator 52
- Additional information 52
- Hardware 52
- Refer to ny series operating systems and software utilities manual cat no w616 for indus trial pc system api for api details 52
- The error led err indicates the presence and type of an error within the industrial box pc 52
- The hard disk drive led hdd indicates activity of the storage device 52
- The run led is available for user applications 52
- The status of this led can also be defined by users using the industrial pc system api refer to ny series operating systems and software utilities manual cat no w616 for in dustrial pc system api for api details refer to 7 2 corrective maintenance on page 7 4 for actions to solve errors 52
- 3 power button 53
- Hardware 53
- 4 1 power connector 54
- 4 2 i o connector 54
- 4 connectors 54
- Hardware 54
- 4 3 usb connectors 55
- Hardware 55
- 4 4 ethernet connectors 56
- 4 5 dvi connector 56
- Hardware 56
- 4 6 rs 232c connector optional 57
- 4 7 dvi d connector optional 57
- Hardware 57
- 4 8 ny monitor link connector optional 58
- Hardware 58
- 4 9 ethernet connector optional 59
- Hardware 59
- 5 sd memory card slot 60
- Hardware 60
- 6 cfast card slot optional 61
- Hardware 61
- 7 drive bays 62
- Hardware 62
- 8 pcie card slot 63
- Hardware 63
- 9 1 battery 64
- 9 2 fan unit 64
- 9 spare parts 64
- Hardware 64
- 9 3 accessory kit 65
- 9 4 connectors 65
- Details for the recommended connectors are provided below omron is not responsible for the operation or performance of any other connector 65
- Hardware 65
- The accessory kit for the box pc 65
- 10 1 mounting brackets 66
- 10 optional hardware 66
- Bracket details per model id 66
- Hardware 66
- Mounting brackets are available for different models of the industrial box pc the model id is available on the id information label 66
- Refer to 1 3 id information label on page 1 4 for label details refer to 3 1 2 base layer on page 3 5 for label location details refer to 1 4 product configuration box pc on page 1 5 for configuration details 66
- The following optional hardware is available for the industrial box pc 66
- 10 2 sd memory cards 67
- Hardware 67
- Refer to 4 1 9 bracket specifications on page 4 17 for bracket dimension details 67
- Sd memory card details are provided below omron is not responsible for the operation performance or write life of any other brand of sd memo ry card 67
- 10 3 usb flash drives 68
- 10 4 cfast cards 68
- Additional information 68
- Cfast card details are provided below omron is not responsible for the operation performance or write life of any other cfast card 68
- Hardware 68
- Refer to cfast card specifications on page 4 13 for cfast card specifications 68
- Usb flash drive details are provided below omron is not responsible for the operation performance or write life of any other brand of usb flash drives 68
- 10 5 hdd and ssd storage devices 69
- Additional information 69
- For a storage device that is not an omron ny000 a consider the following omron is not responsible for the operation performance or write life of any storage device other than those supplied by omron test and measure the environmental performance of the intended storage device before actual op eration using the smart monitoring feature of the selected storage device ensure the temperature and vibrations of the storage device are within the operating temperature specifications and vibration specifications during actual operation using a storage device with maximum power consumption exceeding 2w is not advised ensure that the smart monitor features of the storage device are used to detect overheating 69
- Hardware 69
- Hdd and ssd storage device details are provided below omron is not responsible for the operation performance or write life of any other storage device 69
- Hdd and ssd storage devices can only be installed in models with an expansion layer refer to 1 4 product configuration box pc on page 1 5 for model details 69
- Refer to 4 1 7 storage device specifications on page 4 11 for storage device specifications 69
- Refer to 4 1 7 storage device specifications on page 4 11 for storage device specifications refer to 4 3 1 operation environment specifications on page 4 31 for environment specifi cations specifically temperature and vibration specifications 69
- Storage device considerations 69
- 10 6 dvi cables 70
- 10 7 usb type a to usb type b cables 70
- Dvi cable clearance 70
- Dvi cable details are provided below omron is not responsible for the operation or performance of any other brand of dvi cable 70
- Hardware 70
- The dvi cable requires a minimum clearance of 90 mm from the connector entry to prevent excessive strain on the connector and cable assembly 70
- The usb type a to usb type b cable requires a minimum clearance of 60 mm from the connector entry to prevent excessive strain on the connector and cable assembly 70
- Usb type a to usb type b cable clearance 70
- Usb type a to usb type b cable details are provided below omron is not responsible for the operation or performance of any other brand of usb type a to usb type b cable 70
- 10 8 ny monitor link cables 71
- Hardware 71
- Ny monitor link cable clearance 71
- Nyml recommendations up to 20 m 71
- Pc monitor 71
- Hardware 72
- Ny monitor link cable clearance 72
- Nyml recommendations up to 100 m 72
- Pc monitor infrastructure 72
- Additional information 73
- Ensure to prevent excessive strain on the connector and cable assembly the minimum clearance consists of the sum of connector length maximum bending radius of cable in a fixed position 73
- Hardware 73
- Ny monitor link cable clearance 73
- Nyml recommendations for custom cables 73
- The following table lists the recommended cables and connectors for custom ny monitor link cables 73
- When making cables connect the shield to the connectors at both ends 73
- 10 10 power supply 74
- 10 9 industrial monitor 74
- Additional information 74
- Details for the recommended monitor are provided below omron is not responsible for the operation or performance of any other monitor 74
- Details for the recommended power supply are provided below omron is not responsible for the operation or performance of any other power supply 74
- Hardware 74
- Power supply 74
- Refer to 4 1 3 power consumption specifications on page 4 4 for power consumption de tails refer to the omron website for specifications and manuals note that the power consumption details of the box pc determine the minimum power rating of your power supply 74
- Refer to the omron website for specifications and manuals 74
- 10 11 ups 75
- 10 12 ups communication cable 75
- Hardware 75
- Ups communication cable 75
- 1 general specifications 2 77
- 2 connector specifications 19 77
- 3 environmental specifications 31 77
- Section 4 specifications 77
- Specifications 77
- This section provides specifications of the industrial box pc 77
- 1 1 dimensions and weight 78
- 1 general specifications 78
- Specifications 78
- The following table provides specification details on dimensions and weights 78
- This section provides general specifications of the industrial box pc 78
- 1 2 general electrical specifications 79
- Specifications 79
- The following table provides the general electrical specifications 79
- 1 3 power consumption specifications 80
- Additional information 80
- Calculation for the total power consumption 80
- Connected expansions 80
- Ensure to use a power supply with sufficient capacity refer to 4 1 4 power supply specifications on page 4 5 for details 80
- Installed drives 80
- Specifications 80
- The total power consumption for the box pc is the sum of the power consumption of all installed com ponents refer to 1 4 product configuration box pc on page 1 5 for product configuration details the following tables provide an overview of the components and their power consumption the box pc 80
- 1 4 power supply specifications 81
- Specifications 81
- The minimum power supply requirements depend on the maximum power consumption of the box pc refer to 4 1 3 power consumption specifications on page 4 4 for details 81
- With a ups installed the minimum power requirements are 81
- 1 5 cpu specifications 82
- Celero 82
- Cpu specifications for an inte 82
- E3 1515m v5 cpu 82
- E3 1515m v5 cpu specifications 82
- I7 4700eq cpu 82
- I7 4700eq cpu specifications 82
- Ny 17 inte 82
- Ny 1c inte 82
- Ny 1e inte 82
- Specifications 82
- This section gives the specifications of the cpus that are available for the industrial box pc refer to 1 4 product configuration box pc on page 1 5 for product configuration details 82
- U cpu specifications 82
- Celero 83
- Cpu specifications for an inte 83
- I5 4300u cpu 83
- I5 4300u cpu specifications 83
- Ny 25 inte 83
- Ny 2a inte 83
- Ny 2c inte 83
- Specifications 83
- U cpu specifications 83
- X5 e3940 cpu 83
- X5 e3940 cpu specifications 83
- Cpu specifications for an inte 84
- I5 7300u cpu 84
- I5 7300u cpu specifications 84
- I7 7820eq cpu 84
- I7 7820eq cpu specifications 84
- Ny 27 inte 84
- Ny 35 inte 84
- Specifications 84
- 1 6 memory specifications 85
- Ddr4 ecc 85
- Ddr4 non ecc 85
- Specifications 85
- The following table provides specification details of the ddr4 memory 85
- This section provides the memory specifications of the industrial box pc 85
- Ddr3l non ecc 86
- Specifications 86
- The following table provides specification details of the ddr3l memory 86
- 1 7 storage device specifications 87
- Additional information 87
- For a box pc with storage devices in raid 1 both storage devices are required to be of the same model 87
- Hard disk drive specifications 87
- Raid 1 specifications 87
- Specifications 87
- Specifications for the hard disk drive hdd are provided in the table below 87
- This section provides the specifications of the storage devices 87
- When replacing a raid 1 storage device ensure the replacement storage device is of the same model as the remaining storage device 87
- Additional information 88
- For a box pc with storage devices in raid 1 both storage devices are required to be of the same model 88
- Raid 1 specifications 88
- Solid state drive specifications 88
- Specifications 88
- Specifications for the solid state drive ssd are provided in the table below 88
- When replacing a raid 1 storage device ensure the replacement storage device is of the same model as the remaining storage device 88
- Cfast card specifications 89
- Specifications 89
- Specifications for the cfast drive are provided in the table below 89
- 1 8 pcie card specifications 90
- Ny 1c 1 pcie card slot specifications 90
- Specifications 90
- Celero 91
- E3 1515m v5 cpu 91
- I7 4700eq cpu 91
- Ny 17 1 pcie card slot specifications 91
- Ny 1e 1 ny 1e 2 pcie card slot specifications 91
- Ny 2c 1 pcie card slot specifications 91
- Specifications 91
- The table below provides pcie card slot details for industrial box pcs with an inte 91
- I5 4300u cpu 92
- I5 7300u cpu 92
- I7 7820eq cpu 92
- Ny 25 1 pcie card slot specifications 92
- Ny 27 1 ny 27 2 pcie card slot specifications 92
- Ny 35 1 ny 35 2 pcie card slot specifications 92
- Specifications 92
- The table below provides pcie card slot details for industrial box pcs with an inte 92
- 1 9 bracket specifications 93
- Additional information 93
- Book mount brackets 93
- Refer to 3 10 1 mounting brackets on page 3 22 for bracket ids refer to 5 3 8 book mount procedure on page 5 26 for book mount details 93
- Specifications 93
- The metal mounting brackets mount your box pc 93
- The metal mounting brackets mount your box pc and they are the connection for the functional ground 93
- Additional information 94
- Refer to 3 10 1 mounting brackets on page 3 22 for bracket ids refer to 5 3 9 wall mount procedure on page 5 27 for wall mount details 94
- Specifications 94
- The metal mounting brackets mount your box pc 94
- Wall mount brackets 94
- 2 1 power connector specifications 95
- 2 connector specifications 95
- Specifications 95
- 2 2 i o connector specifications 96
- Locking and removing the power connector 96
- Specifications 96
- Additional information 97
- I o connector pin details 97
- Refer to 5 4 4 wire the i o connector on page 5 39 for i o connector wiring details 97
- Specifications 97
- The pin details of the i o connector 97
- The pin layout represents the i o connector on the box pc the i o signals connected must be powered from a power supply which conforms to the selv stand ards pin details of the i o connector 97
- I o connector power status output details 98
- Power off power status output operation 98
- Power on power status output operation 98
- Specifications 98
- Lock and remove the i o connector 99
- Specifications 99
- 2 3 usb connector specifications 100
- Specifications 100
- 2 4 ethernet connector specifications 101
- Details of the rj45 ethernet connectors are provided below 101
- Details of the rj45 ethernet connectors are provided below the ethernet connector locks automatically to prevent unintentional disconnection 101
- Ethernet connector specification details 101
- Specifications 101
- The set of 3 rj45 ethernet connectors is available on the base layer of all models 101
- Details of the rj45 ethernet connectors in the base layer are provided below 102
- Each connector has led indicators that display the link activity and speed status 102
- Ethernet connector led indicators 102
- Specifications 102
- 2 5 dvi connector specifications 103
- Additional information 103
- Dvi is the standard video interface for the box pc 103
- Refer to 4 1 5 cpu specifications on page 4 6 for graphics controller details refer to 5 4 2 ground on page 5 29 for grounding details refer to a 2 dvi connector pin details on page a 67 for pin details 103
- Specifications 103
- The dvi card specifications depend on the cpu and thus on the product configuration 103
- 2 6 dvi d connector specifications 104
- Specifications 104
- 2 7 rs 232c connector specifications 105
- 2 8 ny monitor link connector specifications 105
- Additional information 105
- Refer to 5 4 2 ground on page 5 29 for grounding details refer to a 3 rs 232c connector pin details on page a 70 for pin details 105
- Specifications 105
- The ny monitor link connector locks automatically to prevent unintentional disconnection 105
- The optional ny monitor link connector connects an omron industrial monitor with an omron in dustrial pc that has an ny monitor link connector the ny monitor link communication is a combination of video and usb information 105
- The optional rs 232c interface on the box pc uses a standard subd9 connector the rs 232c interface is not isolated from the internal box pc s components 105
- And video 106
- Ny monitor link connector led indicators 106
- Specifications 106
- The connector has led indicators connected 106
- 3 1 operation environment specifications 107
- 3 environmental specifications 107
- Specifications 107
- The following table provides the general environmental specifications for the industrial box pc 107
- This section provides environmental specifications of the industrial box pc 107
- 3 2 temperature and humidity specifications 108
- Additional information 108
- Operate the box pc with a hdd within the ambient temperature and humidity ranges as shown in following graph 108
- Operate the box pc with a ssd or cfast within the general environmental specifications 108
- Refer to the ambient temperature specifications per cpu type for specific limitations 108
- Specifications 108
- Temperature and humidity graphs 108
- The allowed ambient operating temperature and ambient humidity depend on the model mounting ori entation and storage device type the following sections provide temperature and humidity details and temperature specifications per model 108
- The maximum ambient operating temperature and ambient humidity are specified per storage device type the following graphs provide ambient temperature and humidity details per storage device type and the conditions for storage 108
- Specifications 109
- Store the box pc with a hdd within the ambient temperature and humidity ranges as shown in fol lowing graph 109
- Store the box pc with a ssd or cfast within the general environmental specifications 109
- Additional information 110
- Ambient operating temperature specifications for model nyb1c 1 110
- Ambient operating temperature specifications for models nyb1e 1 and nyb1e 2 110
- Celero 110
- E3 1515m v5 cpu 110
- Nyb1c 1 temperature specifications 110
- Nyb1e 1 nyb1e 2 temperature specifications 110
- Refer to 1 4 product configuration box pc on page 1 5 for model details 110
- Specifications 110
- This box pc has an inte 110
- Additional information 111
- Ambient operating temperature specifications for model nyb17 1 111
- Ambient operating temperature specifications for model nyb2a 0 111
- I7 4700eq cpu 111
- Nyb17 1 temperature specifications 111
- Nyb2a 0 temperature specifications 111
- Refer to 1 4 product configuration box pc on page 1 5 for model details 111
- Specifications 111
- This box pc has an inte 111
- X5 e3940 cpu 111
- Additional information 112
- Ambient operating temperature specifications for model nyb2c 0 112
- Ambient operating temperature specifications for model nyb2c 1 112
- Celero 112
- Nyb2c 0 temperature specifications 112
- Nyb2c 1 temperature specifications 112
- Refer to 1 4 product configuration box pc on page 1 5 for model details 112
- Specifications 112
- This box pc has an inte 112
- Additional information 113
- Ambient operating temperature specifications for model nyb25 1 113
- I5 4300u cpu 113
- Nyb25 1 temperature specifications 113
- Refer to 1 4 product configuration box pc on page 1 5 for model details 113
- Specifications 113
- This box pc has an inte 113
- Additional information 114
- Ambient operating temperature specifications for model nyb27 0 114
- Ambient operating temperature specifications for model nyb27 1 and nyb27 2 114
- I7 7820eq cpu 114
- Nyb27 0 temperature specifications 114
- Nyb27 1 nyb27 2 temperature specifications 114
- Refer to 1 4 product configuration box pc on page 1 5 for model details 114
- Specifications 114
- This box pc has an inte 114
- Additional information 115
- Ambient operating temperature specifications for model nyb35 0 115
- Ambient operating temperature specifications for models nyb35 1 and nyb35 2 115
- I5 7300u cpu 115
- Nyb35 0 temperature specifications 115
- Nyb35 1 nyb35 2 temperature specifications 115
- Refer to 1 4 product configuration box pc on page 1 5 for model details 115
- Specifications 115
- This box pc has an inte 115
- 3 3 recycling specifications 116
- Precautions for safe use 116
- Specifications 116
- The following table provides recycling information for the industrial box pc 116
- 1 unpack 2 117
- 2 install options 5 117
- 3 mount 16 117
- 4 wire 28 117
- 5 connect 42 117
- 6 initial power on 45 117
- 7 install software 49 117
- 8 connect ups 50 117
- 9 create backup and repair data 56 117
- Installation 117
- Section 5 installation 117
- This section provides all installation details for the industrial box pc 117
- 1 1 unpack procedure 118
- 1 2 items supplied 118
- 1 unpack 118
- Installation 118
- Installation 119
- Items supplied with the industrial box pc 119
- Book mount 120
- Installation 120
- Items supplied with the brackets 120
- Wall mount 120
- 2 1 install raid 1 121
- 2 install options 121
- Installation 121
- 2 2 install a drive 122
- Installation 122
- Installation 123
- Installation 124
- Installation 125
- 2 3 install the pcie card 126
- Installation 126
- Caution 127
- Installation 127
- Installation 128
- Caution 129
- Installation 129
- Installation 130
- Installation 131
- 3 1 installation method in control panels 132
- 3 mount 132
- Installation 132
- Warning 132
- 3 2 product orientation 133
- 3 3 temperature 133
- Distance for cooling 133
- Installation 133
- Installation 134
- Forced air circulation 135
- Forced ventilation 135
- High temperatures 135
- Installation 135
- Natural cooling 135
- 3 4 humidity 136
- 3 5 vibration and shock 136
- Installation 136
- Low temperatures 136
- Room cooling 136
- 3 6 atmosphere 137
- 3 7 electrical environment 137
- Installation 137
- Installation location 137
- Hardware arrangement 138
- Installation 138
- Wire layout for the power supply 138
- External wiring 139
- Installation 139
- Wire external i o signal lines 139
- Wiring routes 139
- Installation 140
- Routing of wiring 140
- Installation 141
- Other precautions 141
- Wiring ducts 141
- 3 8 book mount procedure 142
- Installation 142
- 3 9 wall mount procedure 143
- Installation 143
- 4 1 wiring warnings and cautions 144
- 4 wire 144
- Installation 144
- Warning 144
- 4 2 ground 145
- Caution 145
- Installation 145
- Warning 145
- Considerations for earthing methods 146
- Installation 146
- Equipotential bonding is an earthing method in which steel frames and building structures metal ducts and pipes and metal structures in floors are connected together and make connections to the earth trunk line to achieve a uniform potential everywhere across the entire building we recommend this earthing method the following figure shows an example of an equipotential bonding system connect the main earthing terminal and building structures together with equipotential bonding con ductors and embed the mesh ground line in each floor connect the ground line of each control panel to the equipotential bonding system 147
- Equipotential bonding system 147
- Installation 147
- Installation 148
- Star earthing 148
- Daisy chain 149
- Installation 149
- This is an earthing method to connect the device that is connected with a communications cable other devices and a device that could be a noise source using a daisy chain topology to a common earth electrode this earthing method is not recommended because the device that could be a noise source may inter fere electromagnetically with other devices 149
- Ground connection details 150
- Installation 150
- Crimp terminals 151
- Installation 151
- 4 3 wire the power connector 152
- Installation 152
- Dc power supply 153
- Installation 153
- Power connector wiring materials 153
- Installation 154
- Power connector wiring procedure 154
- 4 4 wire the i o connector 155
- I o connections 155
- I o connector wiring materials 155
- Installation 155
- This section describes how to wire the i o connector 155
- This section describes i o connection details 155
- Use the supplied i o connector to connect the inputs and outputs to the industrial box pc recommended i o conductor sizes for the connector are provided in the table 155
- Additional information 156
- Installation 156
- Refer to 4 2 2 i o connector specifications on page 4 20 for i o connector specifications refer to i o connector power status output details on page 4 22 for power status output de tails refer to 3 10 11 ups on page 3 31 for ups information 156
- I o connector wiring procedure 157
- Installation 157
- 5 1 connector identification 158
- 5 connect 158
- An overview of the connectors of the base layer 158
- Installation 158
- This section describes how to connect the industrial box pc 158
- 5 2 connection procedure 159
- Installation 159
- Installation 160
- 6 1 initial power on procedure 161
- 6 initial power on 161
- Warning 161
- Installation 162
- 6 2 windows startup first time 163
- Installation 163
- Warning 163
- Installation 164
- 7 install software 165
- Installation 165
- 8 connect ups 166
- Installation 166
- Warning 166
- 8 1 connect ups using the usb connector 167
- Installation 167
- Installation 168
- 8 2 connect ups using the i o connector 169
- Installation 169
- Installation 170
- Installation 171
- 9 create backup and repair data 172
- Installation 172
- 1 power on 2 173
- 2 power off 3 173
- 3 react to product messages 5 173
- 4 react to windows messages 6 173
- Operating procedures 173
- Section 6 operating procedures 173
- This section provides the operating procedures for the industrial box pc 173
- 1 1 power on using the power button 174
- 1 2 power on using the power on off input 174
- 1 3 auto power on 174
- 1 power on 174
- Operating procedures 174
- 2 1 power off using the power button 175
- 2 2 power off using windows shut down 175
- 2 power off 175
- Operating procedures 175
- 2 3 power off using the power on off input 176
- 2 4 forced power off using the power button 176
- Operating procedures 176
- 3 react to product messages 177
- Operating procedures 177
- 4 react to windows messages 178
- Operating procedures 178
- 1 preventive maintenance 2 179
- 2 corrective maintenance 4 179
- Maintenance 179
- Section 7 maintenance 179
- This section provides an overview of all maintenance tasks for the industrial box pc 179
- 1 1 preventive maintenance schedule 180
- 1 preventive maintenance 180
- Maintenance 180
- Prevent unscheduled downtime with the following preventive maintenance schedule 180
- Preventive maintenance covers all actions that prevent downtime 180
- 1 2 clean the box pc 181
- Clean the box pc periodically in order to keep it in the best operating condition wipe the box pc with a dry soft cloth 181
- Do not use corrosive substances to clean the product doing so may result in the failure or malfunction 181
- Maintenance 181
- Precautions for safe use 181
- 2 1 warning and error messages 182
- 2 corrective maintenance 182
- Industrial pc support utility 182
- Led indicators 182
- Maintenance 182
- Warning 182
- Maintenance 183
- Windows action center 183
- Windows pop up window 183
- 2 2 remove the cover 184
- Maintenance 184
- 2 3 replace the fan unit 185
- Maintenance 185
- Maintenance 186
- 2 4 replace the battery 187
- Maintenance 187
- Maintenance 188
- 2 5 replace a drive 189
- Maintenance 189
- Maintenance 190
- Maintenance 191
- Maintenance 192
- Maintenance 193
- 2 6 replace the pcie card 194
- Maintenance 194
- Caution 195
- Maintenance 195
- Maintenance 196
- Caution 197
- Maintenance 197
- Maintenance 198
- 2 7 replace the cfast card 199
- Maintenance 199
- Maintenance 200
- A 1 bios a 2 201
- A 2 dvi connector pin details a 67 201
- A 3 rs 232c connector pin details a 70 201
- Appendices 201
- A 1 1 bios overview 202
- A 1 bios 202
- Appendices 202
- Bios setup program 202
- Bios structure 202
- Boot selection popup menu 202
- Warning 202
- Appendices 203
- Bios navigation and function keys 203
- Appendices 204
- Bios password write protection 204
- A 1 2 bios for 205
- A 1 2 bios for 4th generation cpus 205
- Appendices 205
- Bios main 205
- Generation cpus 205
- Appendices 206
- Bios advanced 206
- Changeable bios advanced parameters and their factory default values 206
- Generation cpus 206
- This section provides advanced bios information for 206
- Appendices 207
- Appendices 208
- Appendices 209
- Appendices 210
- Bios chipset 210
- Changeable bios chipset parameters and their factory default values 210
- Generation cpus 210
- This section provides chipset information for 210
- Appendices 211
- Bios boot 211
- Changeable bios boot parameters and their factory default values 211
- Provides boot information and configuration settings 211
- Appendices 212
- Bios save exit 212
- Bios security 212
- Warning 212
- A 1 3 bios for 213
- A 1 3 bios for 6th generation cpus 213
- Appendices 213
- Bios main 213
- Generation cpus 213
- Appendices 214
- Bios advanced 214
- Changeable bios advanced parameters and their factory default values 214
- Generation cpus 214
- This section provides advanced bios information for 214
- Appendices 215
- Appendices 216
- Appendices 217
- Appendices 218
- Appendices 219
- Appendices 220
- Bios chipset 220
- Changeable bios chipset parameters and their factory default values 220
- Generation cpus 220
- Provides bios chipset settings for 220
- Appendices 221
- Appendices 222
- Appendices 223
- Appendices 224
- Appendices 225
- Appendices 226
- Bios chipset details 226
- Changeable bios memory thermal configuration parameters and their factory default values 226
- Generation cpus 226
- Generation cpus with a bios version upto version 008 for all other cpu types or bios versions refer to bios chipset on page a 43 for details 226
- Memory thermal configuration 226
- Provides bios chipset details for the submenu processor memory configuration memory ther mal configuration 226
- This section provides bios chipset details for 226
- Appendices 227
- Changeable bios pci express port parameters and their factory default values 227
- Pci express port 227
- Provides bios chipset details for the submenu platform controller hub pci express configura tion pci express port 227
- Appendices 228
- Bios security 228
- Changeable bios security parameters and their factory default values 228
- Provides security information like bios password and hdd information 228
- Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings selecting non recom mended security settings can put your system at risk 228
- Warning 228
- Appendices 229
- Bios boot 229
- Changeable bios boot parameters and their factory default values 229
- Generation cpus 229
- This section provides bios boot information for the 229
- Appendices 230
- Bios save exit 230
- A 1 4 bios for 231
- A 1 4 bios for 7th generation cpus 231
- Appendices 231
- Bios main 231
- Generation cpus 231
- Appendices 232
- Bios advanced 232
- Generation cpus changeable bios advanced parameters and their factory default values are grouped with the combi nation of your cpu type and the bios version 232
- This section provides advanced bios information for 232
- Appendices 233
- Bios advanced bios up to version 008 233
- Celero 233
- Changeable bios advanced parameters and their factory default values 233
- Generation cpus 233
- I5 7300u with a bios version up to bu 008 233
- This section provides advanced bios information for 233
- U with a bios version up to bv 008 for all other cpu types or bios versions refer to bios advanced on page a 32 for details 233
- Appendices 234
- Appendices 235
- Appendices 236
- Appendices 237
- Appendices 238
- Appendices 239
- Bios advanced bios version 115 and higher 239
- Celero 239
- Changeable bios advanced parameters and their factory default values 239
- Generation cpus 239
- I5 7300u with a bios version bu 115 and higher 239
- This section provides advanced bios information for 239
- U with a bios version bv 115 and higher for all other cpu types or bios versions refer to bios advanced on page a 32 for details 239
- Appendices 240
- Appendices 241
- Bios advanced for cpu type inte 241
- Changeable bios advanced parameters and their factory default values 241
- Generation cpu type inte 241
- I7 7820eq 241
- I7 7820eq for all other cpu types refer to bios advanced on page a 32 for details 241
- This section provides advanced bios information for the 241
- Appendices 242
- Appendices 243
- Bios chipset 243
- Generation cpus changeable chipset parameters and their factory default values are grouped with the combination of your cpu type and the bios version 243
- This section provides chipset information for 243
- Appendices 244
- Bios chipset bios up to version 008 244
- Celero 244
- Changeable bios chipset parameters and their factory default values 244
- Generation cpus 244
- I5 7300u with a bios version up to bu 008 244
- This section provides chipset information for 244
- U with a bios version up to bv 008 for all other cpu types or bios versions refer to bios chipset on page a 43 for details 244
- Appendices 245
- Appendices 246
- Appendices 247
- Appendices 248
- Appendices 249
- Bios chipset details 249
- Changeable bios memory thermal configuration parameters and their factory default values 249
- Generation cpus 249
- Generation cpus with a bios version upto version 008 for all other cpu types or bios versions refer to bios chipset on page a 43 for details 249
- Memory thermal configuration 249
- Provides bios chipset details for the submenu processor memory configuration memory thermal configuration 249
- This section provides bios chipset details for 249
- Appendices 250
- Changeable bios pci express port parameters and their factory default values 250
- Pci express port 250
- Provides bios chipset details for the submenu platform controller hub pci express configu ration pci express port 250
- Appendices 251
- Bios chipset bios version 115 and higher 251
- Celero 251
- Changeable bios chipset parameters and their factory default values 251
- Generation cpus 251
- I5 7300u with a bios version bu 115 and higher 251
- This section provides chipset bios information for 251
- U with a bios version bv 115 and higher for all other cpu types or bios versions refer to bios chipset on page a 43 for details 251
- Appendices 252
- Appendices 253
- Bios chipset for cpu type inte 253
- Changeable bios chipset parameters and their factory default values 253
- Generation cpu type inte 253
- I7 7820eq 253
- I7 7820eq for all other cpu types refer to bios chipset on page a 43 for details 253
- This section provides chipset information for the 253
- Appendices 254
- Appendices 255
- Bios security 255
- Changeable bios security parameters and their factory default values 255
- Provides security information like bios password and hdd information 255
- Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings selecting non recom mended security settings can put your system at risk 255
- Warning 255
- Appendices 256
- Bios boot 256
- Generation cpus changeable boot parameters and their factory default values are grouped with the combination of your cpu type and the bios version 256
- This section provides boot information for 256
- Appendices 257
- Bios boot bios up to version 008 257
- Changeable bios boot parameters and their factory default values 257
- Generation cpus with a bios version up to b 257
- This section provides bios boot information for 257
- Appendices 258
- Bios boot bios version 115 and higher 258
- Celero 258
- Changeable bios boot parameters and their factory default values 258
- Generation cpus 258
- I5 7300u with a bios version bu 115 and higher 258
- This section provides advanced bios information for 258
- U with a bios version bv 115 and higher for all other cpu types or bios versions refer to bios advanced on page a 32 for details 258
- Appendices 259
- Bios boot for cpu type inte 259
- Changeable bios boot parameters and their factory default values 259
- I7 7820eq 259
- This section provides bios boot information for cpu type inte 259
- Appendices 260
- Bios save exit 260
- A 1 5 bios for atom cpus 261
- Appendices 261
- Bios main 261
- Appendices 262
- Bios advanced 262
- Changeable bios advanced parameters and their factory default values 262
- This section provides advanced bios information for a box pc with an atom cpu 262
- Appendices 263
- Bios chipset 263
- Changeable bios chipset parameters and their factory default values 263
- This section provides chipset information for a box pc with an atom cpu 263
- Appendices 264
- Bios security 264
- Changeable bios security parameters and their factory default values 264
- Provides security information like bios password and hdd information for a box pc with an atom cpu 264
- Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings selecting non recom mended security settings can put your system at risk 264
- Warning 264
- Appendices 265
- Bios boot 265
- Changeable bios boot parameters and their factory default values 265
- Provides boot information and configuration settings for a box pc with an atom cpu 265
- Appendices 266
- Bios save exit 266
- A 2 1 dvi i connector pin details 267
- A 2 dvi connector pin details 267
- Appendices 267
- Pin details of the dvi i connector 267
- The pin layout represents the dvi i connector on the industrial box pc pin numbers increase from left to right for every row 267
- This section provides the pin details for the dvi i connector and for the optional dvi d connector 267
- A 2 2 dvi d connector pin details 268
- Appendices 268
- Pin details of the dvi d connector 268
- Refer to 1 4 product configuration box pc on page 1 5 for details 268
- The pin layout represents the dvi connector on the industrial box pc pin numbers increase from left to right for every row 268
- Appendices 269
- 2 3 4 5 270
- A 3 rs 232c connector pin details 270
- Additional information 270
- Appendices 270
- The pin layout represents the rs 232c connector on the box pc 270
- Authorized distributor 276
- Contact 276
- Contact www ia omron com 276
- Industrial automation company 276
- Omron corporatio 276
- Regional headquarters 276
Похожие устройства
- Omron NYB1E-C13D1 Спецификация
- Omron NYB1E-C13D1 Руководство пользователя
- Omron NYB1E-C13D2 Спецификация
- Omron NYB1E-C13D2 Руководство пользователя
- Omron NYB1E-C13D6 Спецификация
- Omron NYB1E-C13D6 Руководство пользователя
- Omron NYB1E-C13D9 Спецификация
- Omron NYB1E-C13D9 Руководство пользователя
- Omron NYB1E-C13E1 Спецификация
- Omron NYB1E-C13E1 Руководство пользователя
- Omron NYB1E-C13E2 Спецификация
- Omron NYB1E-C13E2 Руководство пользователя
- Omron NYB1E-C13E6 Спецификация
- Omron NYB1E-C13E6 Руководство пользователя
- Omron NYB1E-C13K1 Спецификация
- Omron NYB1E-C13K1 Руководство пользователя
- Omron NYB1E-C13K2 Спецификация
- Omron NYB1E-C13K2 Руководство пользователя
- Omron NYB1E-C13K6 Спецификация
- Omron NYB1E-C13K6 Руководство пользователя
