3-3
Power Button
The power button is located at the base layer.
The power button is used to manually switch the Box PC ON and OFF.
Additional Information
• Refer to 6-1 Power ON on page 6-2 for ON details.
• Refer to
6-2 Power OFF on page 6-3 for OFF details.
3 Hardware
3-9
NY-series Industrial Box PC Hardware User's Manual (W553)
3-3 Power Button
3
