1-5
Overall Setup Procedure
This section gives the overall setup procedure for the Industrial PC.
This manual presents this information in the same order as the following setup procedure.
To setup the Industrial PC:
1 Familiarize yourself with the Industrial PC
• Refer to the information in this manual.
Specifically refer to following sections of this manual:
• Se
ction 2 System Configurations on page 2-1
• Section 3 Hardware on page 3-1
• Section 4 Specifications on page 4-1
• Refer to the information in related manual NY-series Operating Systems and Software
Utilities Manual (Cat. No. W616).
2 Install the IPC Hardware
Perform the procedures that are required to use the Industrial PC such as installation, and con-
nection with peripheral devices including a UPS.
Refer to S
ection 5 Installation on page 5-1.
3 Setup the IPC
Install and configure the operating system, the software support utilities and the UPS software.
Refer to the information in related manual NY-series Operating Systems and Software Utilities
Manual (Cat. No. W616).
4 Operate the IPC
Use the operating procedures to operate the Industrial PC.
Refer to:
• S
e
ction 6 Operating Procedures on page 6-1
• "Section Operating Procedures" in related manual NY-series Operating Systems and
Software Utilities Manual (Cat. No. W616)
The setup of the Industrial PC is finished.
The section 'Maintenance' contains preventive and corrective maintenance information.
Refer to:
• Section 7 Maintenance on page 7-1
• "Section Maintenance" in related manual NY-series Operating Systems and Software Utilities
Manual (Cat. No. W616)
1 Overview
1-7
NY-series Industrial Box PC Hardware User's Manual (W553)
1-5 Overall Setup Procedure
1
