1-1
Intended Use
The Industrial Box PC is an industrial-grade PC intended for use within factory automation environ-
ments. This Industrial Box PC simultaneously uses the standard Windows operating system and pro-
grams as well as third-party software to serve as a powerful PC platform.
The Industrial Box PC can easily be integrated in manufacturing innovations like big data, NUI and
IIoT.
The Industrial Box PC has a compact design that offers flexibility, expandability and easy maintenance
for applications in factory automation environments.
