When the Industrial Box PC is
not powered for 6 months
Reference
For a cooling layer with removable
cover and active cooling:
• Confirm both fans rotate immedi-
ately after Power ON.
• Replace the Fan Unit when the
fans do not rotate smoothly.
Refer to 7-2-3 Replace the Fan Unit on page
7-7 to replace the Fan
Unit.
7-1-2
Clean the Box PC
Clean the Box PC periodically in order to keep it in the best operating condition.
Wipe the Box PC with a dry, soft cloth.
Precautions for Safe Use
Do not use corrosive substances to clean the product.
Doing so may result in the failure or malfunction.
7 Maintenance
7-3
NY-series Industrial Box PC Hardware User's Manual (W553)
7-1 Preventive Maintenance
7
7-1-2 Clean the Box PC
