Omron NYB1E-C13C6 [56/276] Hardware
![Omron NYB1E-D13D6 [56/276] Hardware](/views2/1872506/page56/bg38.png)
3-4-4
Ethernet Connectors
The Ethernet connectors provide 3 individual Ethernet ports on the Industrial Box PC.
Each port of
fers 10BASE-T/100BASE-TX/1000BASE-T Ethernet speeds.
Additional Information
• Refer to 4-2-4 Ethernet Connector Specifications on page 4-25 for specifications.
•
Refer to 5-5 Connect on page 5-42 for connection details.
3-4-5
DVI Connector
The DVI interfaces supported on this connector are dependent on the configuration of the Industrial
Box PC.
Additional Information
• Refer to 1-4 Product Configuration Box PC on page 1-5 for configuration details.
• Refer to
4-2-5 DVI Connector Specifications on page 4-27 for specifications.
• Refer to 5-5 Connect on page 5-42 for connection details.
3 Hardware
3-12
NY-series Industrial Box PC Hardware User's Manual (W553)
