Omron NYB1E-C13C6 [35/276] 2 hardware features
![Omron NYB1E-413C2 [35/276] 2 hardware features](/views2/1872506/page35/bg23.png)
1-2
Hardware Features
The Industrial Box PC provides the following hardware features:
• Compact design with two mounting orientation options
The Box PC has a compact design to minimize panel space while allowing for two mounting orienta-
tions.
• Powerful CPU options
Powerful CPU options provide high performance for various applications.
• Fanless cooling for multiple CPU types
The Box PC has passive cooling for multiple CPU types which means no moving parts and less
maintenance effort.
• Easy access to storage devices and the PCI Express Card
Adding or changing storage devices (HDD, SSD) and PCI Express Card is fast and simple.
• RAID support
RAID 0 and RAID 1 are supported. For 4
th
generation CPUs starting with Main BIOS
version A£27R110. Hot-swap of storage devices is not supported.
• LED indicators
LED indicators provide a clear indication of the operational status of the Box PC.
• DVI visual interface
The video interface for the Box PC is provided with a DVI connector for connection to a monitor.
An extra (optional) DVI interface is available for connection to a second monitor.
• NY Monitor Link interface
The interface combines video signals and USB signals for a connection to an OMRON Industrial
Monitor using a single NY Monitor Link cable up to 100 meter.
• 3 Ethernet ports 1Gb/s
Interface with multiple networks. An extra (optional) 4
th
1Gb/s Ethernet port can be added.
• Built-in I/O
Built-in I/O for UPS status and Box PC shutdown control are provided.
• 4 USB ports
2 USB2.0 ports and 2 USB3.0 ports are provided for connection to external USB devices such as
keyboards, memory sticks, or other peripheral hardware.
• Built-in SD Memory Card slot
An SD Memory Card slot is provided for removable memory.
• Built-in CFast Card slot
An optional CFast Card slot is provided as a removable storage device.
1 Overview
1-3
NY-series Industrial Box PC Hardware User's Manual (W553)
1-2 Hardware Features
