BIOS - Advanced
This section provides Advanced BIOS information for a Box PC with an Atom CPU.
Changeable BIOS Advanced parameters and their factory default values:
Item Default / Remark
Trusted Computing Security Device Support Enabled
SHA-1 PCR Bank Enabled
SHA256 PCR Bank Enabled
Pending operation None
Platform Hierarchy Enabled
Storage Hierarchy Enabled
Endorsement Hierarchy Enabled
TPM2.0 UEFI Spec Version TCG_2
Physical Presence Spec Version 1.3
Device Select Auto
RTC Wake Settings RTC Wake Mode Disabled
CPU CPU Power Manage-
ment
EIST Enabled
Turbo Mode Enabled
C-States Disabled
Active Processor Cores Disabled
Intel Virtualization Technology Enabled
VT-d Enabled
Monitor Mwait Auto
AMI Graphic Output
Protocol Policy
Output Select DVI2
UEFI Network Stack UEFI Network Stack Disabled
CSM & Option ROM
Control
CSM Support Disabled
USB Legacy USB Support Enabled
xHCI Hand-off Enabled
USB Mass Storage Driver Support Enabled
USB Transfer Timeout 20 sec
Device Reset Timeout 20 sec
Device Power-up Delay Selection Auto
Generic Ultra HS-COMBO Auto
