NYML Recommendations for Custom Cables
The following table lists the recommended cables and connectors for custom NY Monitor Link cables.
Item
Intra cabinet or
light industrial en-
vironment
Inter cabinet
Inter cabinet and
harsh industrial
environment
Maximum length 25 m 100 m 100 m
Manufacturer Lapp Lapp Lapp
Cable type 2170196 2170614 2170466
Category type Cat 6A Cat 7 Cat 6A
Cable sheath Halogen free Halogen free Halogen free
Conductor pairs/size/type 4 x 2 x AWG23/1 4 x 2 x AWG23/1 4 x 2 x AWG22/1
Overall shielding Aluminum foil Copper braid Copper braid
Pair shielding Aluminum foil Aluminum foil Aluminum foil
Maximum outer diameter 7.6 mm 7.7 mm 9.0 mm
Maximum bending radius of cable in a fixed
position
31 mm 31 mm 90 mm
Maximum temperature for a cable in a fixed
position
60°C 60°C 80°C
RJ45 connectors Manufacturer Stewart Connector Stewart Connector Lapp
Partnumber SS39200-027 or
SS39200-030
SS39200-027 or
SS39200-030
21700600 (T568A)
or 21700601
(T568B)
Connector length 30 mm 30 mm 50 mm
Additional Information
When making cables, connect the shield to the connectors at both ends.
NY Monitor Link Cable Clearance
Ensure to prevent excessive strain on the connector and cable assembly.
The minimum clearance consists of the sum of:
• Connector length
• Maximum bending radius of cable in a fixed position
3 Hardware
3-29
NY-series Industrial Box PC Hardware User's Manual (W553)
3-10 Optional Hardware
3
3-10-8 NY Monitor Link Cables
