4-1-7
Storage Device Specifications
This section provides the specifications of the storage devices.
Hard Disk Drive Specifications
Specifications for the Hard Disk Drive (HDD) are provided in the table below.
Item
Model Specifications
320 GB
*1
500 GB
*1
1 TB
*1
Model
*2
NY000-AH00 NY000-AH01 NY000-AH02
Power consumption 2 W max.
S.M.A.R.T. support Yes
Rotation speed 5,400 r/min
Interface Serial ATA 3.0
Operating temperature
5 to 55°C
*3
0 to 60°C
*3
Operating humidity (with
no condensation)
• 8 to 90% RH
• 29°C wet-bulb temperature max.
Storage temperature -40 to 65°C
Storage humidity (with
no condensation)
• 8 to 90% RH
• 40°C wet-bulb temperature max.
• 5 to 95% RH
• 40°C wet-bulb temper-
ature max.
Endurance Approximately 5 years or 20,000 powered-ON hours
(whichever comes first) under the following conditions:
• 25°C at 101.3 kPa
• Less than 333 powered-ON hours/month
*4
• Less than 20% operation while powered-ON
*5
• Less than 1.30 x 10
6
seeks/month
Average Annualized
Failure Rate (AFR):
0.50% under the follow-
ing conditions:
• Case Temperature
40°C
• Power on Hours
(POH) ≤ 3120
*1. Refer to 1-4 Product Configuration Box PC on page 1-5 for product configuration details.
*2. Refer to
3-10-5 HDD and SSD Storage Devices on page 3-25 for brand details.
*3. Refer to 4-3-1 Operation Environment Specifications on page 4-31 for the temperature specifications of the
complete Box PC
*4. Powered-ON hours include sleep and standby modes.
*5. Operation includes seeking, writing, and reading functions.
RAID 1 Specifications
For a Box PC with storage devices in RAID 1 both storage devices are required to be of the same
model.
Additional Information
When replacing a RAID 1 storage device, ensure the replacement storage device is of the
same model as the remaining storage device.
4 Specifications
4-11
NY-series Industrial Box PC Hardware User's Manual (W553)
4-1 General Specifications
4
4-1-7 Storage Device Specifications
