1-4
Product Configuration Box PC
This section provides an overview of the product configurations available for the Industrial Box PC.
The product configuration is visible in the model-ID that is mentioned on the ID information label of the
product.
The structure of the model-ID is: NYB££-£££££.
Each item in the model-ID has a specific meaning.
N Y B
1 2
3 4 5 6 7
Item Description Option / Description
1 Series name NYB: NY- series Industrial Box PC
2 Processor
1C: Intel
®
Celeron
®
2980U, 4
th
generation CPU
1E: Intel
®
Xeon
®
E3-1515M v5
6
th
generation CPU with active cooling
17: Intel
®
Core
™
i7-4700EQ
,
4
th
generation CPU with active cooling
2A: Intel
®
Atom
®
x5-E3940
2C: Intel
®
Celeron
®
3965U, 7
th
generation CPU
25: Intel
®
Core
™
i5-4300U, 4
th
generation CPU
27: Intel
®
Core
™
i7-7820EQ,
7
th
generation CPU with active cooling
35: Intel
®
Core
™
i5-7300U, 7
th
generation CPU
3 Main memory 1: 2 GB, non-ECC
2: 4 GB, non-ECC
3: 8 GB, non-ECC
4: 16 GB, non-ECC
5: 32 GB, non-ECC
C: 8 GB, ECC
D: 16 GB, ECC
4 Expansion slots 0: None
1: 1 PCIe slot
2: 1 PCIe slot + Storage hardware RAID 1
5 Operating system 0: No Operating System
1: Windows Embedded Standard 7 - 32 bit
2: Windows Embedded Standard 7 - 64 bit
3: Windows 10 IoT Enterprise 2016 L
TSB - 64 bit
4: Windows 10 IoT Enterprise 2019 LTSC - 64 bit
1 Overview
1-5
NY-series Industrial Box PC Hardware User's Manual (W553)
1-4 Product Configuration Box
PC
