4-3

Environmental Specifications

This section provides environmental specifications of the Industrial Box PC.

4-3-1

Operation Environment Specifications

The following table provides the general environmental specifications for the Industrial Box PC.

Item Specifications

Ambient operating temperature

0 to 55°C

Ambient storage temperature

-20 to 70°C

Ambient operating humidity 10% to 90% with no condensation

Ambient storage humidity 10% to 90% with no condensation

Operating atmosphere No corrosive gases

Altitude 2,000 m max.

Noise resistance (during operation) Conforms to IEC61000-4-4, 2kV (power lines)

Vibration resistance (during opera-

tion)

Conforms to IEC 60068-2-6.

For a Box PC with an SSD: 5 to 8.4 Hz with 3.5 mm single amplitude and

8.4 to 150 Hz with 9.8 m/s² for 10 times each in X, Y and Z directions.

For a Box PC with a HDD the vibration resistance depends on the mount-

ing orientation

Shock resistance (during operation) Conforms to IEC 60068-2-27.

147 m/s², 3 times in each X, Y and Z directions

Pollution degree JIS B3502 and IEC 61131-2: 2 or less

RTC accuracy At ambient temperature of 55°C: −3.5 to +0.5 min error per month

At ambient temperature of 25°C:

−1.5 to +1.5 min error per month

At ambient temperature of 0°C: −3 to +1 min error per month

*1. Refer to 4-3-2 Temperature and Humidity Specifications on page 4-32 for ambient operating temperature

details per CPU type.

*2. Vibration resistance depends on the Box PC's mounting orientation and storage device type:

Mounting Orientation SSD or CFast Card HDD

Book 9.8 m/s² 2.5 m/s²

Wall 4.9 m/s²
