![Omron NYB1E-D1006 [219/276] Appendices](/views2/1872506/page219/bgdb.png)
Item Default / Remark
CSM & Option ROM
Control
CSM Support Enabled
Gate A20 Active Upon Request
Option ROM Messages Force BIOS
INT19 Trap Response Immediate
Boot Option Filter UEFI and Legacy
PXE Option ROM Launch Policy UEFI ROM Only
Storage Option ROM Launch Policy UEFI ROM Only
Video Option ROM Launch Policy Legacy ROM Only
Other Option ROM Launch Policy UEFI ROM Only
SDIO Configuration SDIO Access Mode Auto
USB Overcurrent Protection Disabled
Legacy USB Support Enabled
xHCI Hand-off Enabled
USB Mass Storage Driver Support Enabled
USB Transfer Timeout 20 sec
Device Reset Timeout 20 sec
Device Power-up Delay Selection Auto
Generic Ultra HS-COMBO Auto
Diagnostic Settings Relay Interface Disabled
BC Diagnostic Console Interface Disabled
Appendices
A-19
NY-series Industrial Box PC Hardware User's Manual (W553)
A-1 BIOS
A
A-1-3 BIOS for 6
th
generation CPUs
