BIOS - Chipset BIOS version 115 and higher
This section provides Chipset BIOS information for 7
th
generation CPUs:
• Intel
®
Core
™
i5-7300U
with a BIOS version BU£££115 and higher
• Intel
®
Celeron
®
3965U with a BIOS version BV£££115 and higher
For all other CPU types or BIOS versions refer to BIOS - Chipset on page A-43 for details.
Changeable BIOS Chipset parameters and their factory default values:
Item Default / Remark
Processor
(Integrated
Components)
Memory Configuration Max TOLUD Dynamic
Memory Remap Enabled
Graphics Configura-
tion
Primary Display Auto
Select PCIE Card Auto
Internal Graphics Device Auto
GTT Size 8MB
Aperture Size 256MB
IGD Pre-Allocated Graphics Mem-
ory
32M
IGD Total Graphics Memory 256M
GOP Config Driver Enabled
VT-d Enabled
Above 4GB MMIO BIOS assignment Disabled
Appendices
A-51
NY-series Industrial Box PC Hardware User's Manual (W553)
A-1 BIOS
A
A-1-4 BIOS for 7
th
generation CPUs
