Omron NYB1E-C13C6 [169/276] 8 2 connect ups using the i o connector
![Omron NYB1E-C13C6 [169/276] 8 2 connect ups using the i o connector](/views2/1872506/page169/bga9.png)
Additional Information
• The default Input sensitivity setting is Standard voltage sensitivity and this is correct.
Do not set this parameter to Low voltage sensitivity. Doing so can cause a system malfunc-
tion when switching to battery mode.
•
The UPS Setting Utility can not be used when the Power Attendant Lite Utility is active.
To use the UPS Setting Utility:
1. Right-click the Power Attendant Lite Utility icon and select Agent Stop.
2. Use the UPS Setting Utility.
3. Right-click the Power Attendant Lite Utility icon and select Agent Start.
5-8-2
Connect UPS Using the I/O Connector
The I/O connector of the Industrial Box PC:
•
receives the power status of the UPS with the UPS Mode Input when the Box PC has a Windows
operating system. For other operating systems this input is not functional.
• indicates the power status of the Box PC
to the UPS with the Power Status Output.
Additional Information
• A UPS connection using the I/O connector is only possible for a Box PC with a Windows op-
erating system. For all other operating systems use the USB connector to connect the UPS.
Refer to 5-8-1 Connect UPS Using the USB Connector on page 5-51 for details.
•
The Box PC does not react automatically to the UPS Mode Input.
A custom software program is required to shut down the Box PC when needed.
UPS Drivers and the required software is available.
• For Box PCs with Windows 10 or Windows 7 preinstalled:
• Drivers for the S8BA UPS are pre-installed
•
Installation files and manual for the UPS Settings Utility are availabe in the installer directory
D:\OMRON-NY\Installers\ UPS Settings Utility
• For all other Box PCs following software can be downloaded:
• Drivers for the S8BA UPS from
this OMRON website.
• Installation files and manual for the UPS Settings Utility (Windows only) from this OMRON web-
site.
Precautions for Safe Use
• Always use the recommended uninterruptible power supply (UPS) to prevent data loss and
other system file integrity issues caused by unexpected power interruption.
• Use an Omron S8BA UPS with the correct revision number to prevent improper system shut-
down.
• Correctly perform wiring and setting, and ensure that the shutdown by the UPS can be exe-
cuted.
Follow the steps below to connect the S8BA UPS to the I/O connector of the Box PC and to configure
it correctly.
Refer to 5-4-4 W
ire the I/O Connector on page 5-39 for I/O Connector details.
1 Ensure the revision number of the UPS is correct.
Refer to 3-10-11 UPS
on page 3-31 for more information.
5 Installation
5-53
NY-series Industrial Box PC Hardware User's Manual (W553)
5-8 Connect UPS
5
5-8-2 Connect UPS Using the I/O Connector
