A-1-5
BIOS for Atom CPUs
The BIOS settings for Atom CPUs.
The BIOS is divided in the pages Main, Advanced, Chipset, Security
, Boot and Save&Exit.
BIOS - Main
The main setup screen gives platform information about the BIOS, Board Information, Firmware Revi-
sion, MAC Addresses and information about the number of Boots and the Running Time. Platform In-
formation gives CPU and platform details.
Changeable BIOS Main parameters and their factory default values:
• System Date
Use the Enter
key to the next Date field.
• System Time
Use the Enter key to the next Time field.
Appendices
A-61
NY-series Industrial Box PC Hardware User's Manual (W553)
A-1 BIOS
