3-4-6
RS-232C Connector (Optional)
Depending on the product configuration an optional RS-232C connector is available.
Additional Information
• Refer to 1-4 Product Configuration Box PC on page 1-5 for configuration details.
• Refer to
4-2-7 RS-232C Connector Specifications on page 4-29 for specifications.
• Refer to 5-5 Connect on page 5-42 for connection details.
3-4-7
DVI-D Connector (Optional)
Depending on the product configuration an optional DVI-D connector is available. This interface only
supports digital video signals.
Additional Information
• Refer to 1-4 Product Configuration Box PC on page 1-5 for configuration details.
• Refer to
4-2-6 DVI-D Connector Specifications on page 4-28 for specifications.
• Refer to 5-5 Connect on page 5-42 for connection details.
3 Hardware
3-13
NY-series Industrial Box PC Hardware User's Manual (W553)
3-4 Connectors
3
3-4-6 RS-232C Connector (Optional)
