Omron NYB1E-C13C6 [269/276] Appendices
![Omron NYB1E-C13C6 [269/276] Appendices](/views2/1872506/page269/bg10d.png)
Pin Signal Name Function
15 0 V Return for pin 14
16 HPD Hot plug detect
17 TMDS data 0− Digital blue− (link 1) and digital sync
18 TMDS data 0+ Digital blue+ (link 1) and digital sync
19 0 VDC TMDS data 0/5 shield
20 Not connected ---
21 Not connected ---
22 0 VDC TMDS clock shield
23 TMDS clock+ Digital clock+
24 TMDS clock− Digital clock−
C5 Not connected ---
Appendices
A-69
NY-series Industrial Box PC Hardware User's Manual (W553)
A-2 DVI Connector Pin Details
A
A-2-2 DVI-D Connector Pin Details
