4-1-6
Memory Specifications
This section provides the memory specifications of the Industrial Box PC.
DDR4 ECC
The following table provides specification details of the DDR4 memory.
Item
Model Specifications
*1
8 GB 16 GB
Memory configuration 2 x 4 GB 2 x 8 GB
Memory type DDR4 ECC
Package memory format SO-DIMM
Serial Presence Detect
(SPD)
Speed grade
*2
2400 MT/s
CAS Latency CL17
*1. The applicable type of memory is determined by the CPU type.
Refer to 4-1-5 CPU Specifications on page 4-6 for CPU details.
Refer to 1-4 Product Configuration Box PC on page
1-5 for product configuration details.
*2. The actual speed depends on the CPU type.
DDR4 Non-ECC
The following table provides specification details of the DDR4 memory.
Item
Model Specifications
*1
4 GB 8 GB 16 GB 32 GB
Memory configuration 1 x 4 GB 2 x 4 GB 2 x 8 GB 2 x 16 GB
Memory type DDR4 Non-ECC
Package memory format SO-DIMM
Serial Presence
Detect (SPD)
Speed grade
*2
2400 MT/s
CAS Latency CL17
*1. The applicable type of memory is determined by the CPU type.
Refer to 4-1-5 CPU Specifications on page 4-6 for CPU details.
Refer to 1-4 Product Configuration Box PC on page
1-5 for product configuration details.
*2. The actual speed depends on the CPU type.
4 Specifications
4-9
NY-series Industrial Box PC Hardware User's Manual (W553)
4-1 General Specifications
4
4-1-6 Memory Specifications
