NYB1C-£1 Temperature Specifications
Ambient operating temperature specifications for model NYB1C-£1.
This Box PC has an Intel
®
Celeron
®
2980U CPU.
Additional Information
Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
Mounting Orientation
Storage device type
*1
SSD HDD 320 GB / 500 GB HDD 1 TB
Book 0 to 55°C 5 to 45°C 0 to 40°C
Wall 0 to 50°C 5 to 40°C 0 to 35°C
*1. Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
NYB1E-£1, NYB1E-£2 T
emperature Specifications
Ambient operating temperature specifications for models NYB1E-£1 and NYB1E-£2.
This Box PC has an Intel
®
Xeon
®
E3-1515M v5 CPU.
Additional Information
Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
Mounting Ori-
entation
Storage device type
*1
1 x SSD 2 x SSD
1 x HDD
*2
2 x HDD
*2
1 x SSD 1 x
HDD
*2
Book 0 to 55°C 5 to 45°C 5 to 30°C 5 to 45°C
Wall 0 to 55°C 5 to 40°C 5 to 30°C 5 to 40°C
*1. Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
*2. Ambient operating temperature specifications when using a 1 TB HDD:
Mounting Orientation
Storage device type
1 x HDD 2 x HDD 1 x SSD 1 x HDD
Book 0 to 40°C 5 to 30°C 0 to 35°C
Wall 0 to 40°C 5 to 30°C 0 to 35°C
4 Specifications
