![Omron NYB1E-313D6 [259/276] I7 7820eq](/views2/1872506/page259/bg103.png)
BIOS - Boot for CPU Type Intel
®
Core
™
i7-7820EQ
This section provides BIOS Boot information for CPU type Intel
®
Core
™
i7-7820EQ.
Changeable BIOS Boot parameters and their factory default values:
Item Default / Remark
Quiet Boot Disabled
Setup Prompt Timeout 1
Bootup NumLock State On
Power Loss Control
*1
Remain Off
Enter Setup If No Boot Device No
Enable Popup Boot Menu Yes
Boot Priority Selection Type Based
Boot Option #1
Windows Boot Manager (P1: £)
Boot Option #2
UEFI OS (P1: £)
UEFI Fast Boot Disabled
UEFI Screenshot Capability Disabled
New Boot Option Policy Default
*1. Power Loss Control settings are :
Remain OFF: The Industrial Box PC will stay OFF when power is supplied to the power connector
T
urn ON: The Industrial Box PC will automatically start up when power is supplied to the power connec-
tor
.
Last State: The Industrial Box PC will start up or remain OFF when power is supplied based on the In-
dustrial Box PC
state at the moment power was removed from the power connector.
