BIOS - Advanced for CPU Type Intel
®
Core
™
i7-7820EQ
This section provides Advanced BIOS information for the 7
th
generation CPU type Intel
®
Core
™
i7-7820EQ.
For all other CPU types refer to
BIOS - Advanced on page A-32 for details.
Changeable BIOS Advanced parameters and their factory default values:
Item Default / Remark
CPU SW Guard Extensions (SGX) Software Controlled
Select Owner EPOCH input type No Change in Owner
EPOCHs
Hardware Prefetcher Enabled
Adjacent Cache Line Prefetch Enabled
Intel (VMX) Virtualization Technology Enabled
Active Processor Cores All
Hyper-Threading Enabled
BIST Disabled
AP threads Idle Manner MWAIT Loop
AP threads Handoff Manner MWAIT Loop
AES Enabled
MachineCheck Enabled
MonitorMWait Enabled
Power & Performance CPU - Power Man-
agement Control
Boot performance mode Max Non-Turbo Per-
formance
Intel ® SpeedStep ™ Enabled
Race To Halt (RTH) Enabled
Intel ® Speed Shift Technology Enabled
Turbo Mode Enabled
C states Disabled
Timed MWAIT Disabled
GT - Power Manage-
ment Control
Maximum GT frequency Default Max Frequen-
cy
Graphics Digital Display Interface 1 Auto Selection
Digital Display Interface 2 Auto Selection
VGA Port Enabled
DisplayPort Spread Spectrum Clock Disabled
Hardware Health
Monitoring
Fan Control Temperature CPU Temperature
Lower Temperature Threshold 50 C
Upper Temperature Threshold 80 C
Minimum Fan Speed Fan Off
Lower Temperature Fan Speed 30%
Upper Temperature Fan Speed 100%
Maximum Fan Speed 100%
Appendices
A-41
NY-series Industrial Box PC Hardware User's Manual (W553)
A-1 BIOS
A
A-1-4 BIOS for 7
th
generation CPUs
