![Omron NYB1E-D13E1 [215/276] Appendices](/views2/1872506/page215/bgd7.png)
Item Default / Remark
Power & Performance CPU - Power Manage-
ment Control
Boot performance mode Max Non-Turbo Per-
formance
Intel ® SpeedStep ™ Enabled
Race To Halt (RTH) Enabled
Intel ® Speed Shift Technology Enabled
HDC Control Enabled
Turbo Mode Enabled
CPU - Power Management Control /View/Configure Turbo Options
Package Power Limit MSR Lock Disabled
1-Core Ratio Limit Override 37
2-Core Ratio Limit Override 36
3-Core Ratio Limit Override 35
4-Core Ratio Limit Override 33
Energy Efficient Turbo Enabled
CPU - Power Management Control /Config TDP Configurations
Configurable TDP Boot Mode Nominal
Configurable TDP Lock Disabled
CTDP BIOS control Disabled
Power Limit 1 0
Power Limit 2 0
Power Limit 1 Time Window 0
ConfigTDP Turbo Activation Ratio 0
Power Limit 1 0
Power Limit 2 0
Power Limit 1 Time Window 0
ConfigTDP Turbo Activation Ratio 0
CPU - Power Management Control / CPU VR Settings
PSYS Slope 0
PSYS Offset 0
PSYS PMax Power 0
Acoustic Noise Settings Acoustic Noise Mitiga-
tion
= Disabled
Appendices
A-15
NY-series Industrial Box PC Hardware User's Manual (W553)
